Lightwave LW-PC-LCU-LCU-DX-SM-1M LC UPC Single Mode Duplex Patch Cord 1m
Original price was: KSh 600.00.KSh 500.00Current price is: KSh 500.00. ex VAT
Lightwave LW-PC-LCU-LCU-DX-SM-1M LC UPC Single Mode Duplex Patch Cord 1m
| Connectors | LC UPC to LC UPC |
| Fiber Type | Single Mode 9/125µm |
| Length | 1.0 Meter |
| Jacket | LSZH Duplex |
Shipping & Delivery
Delivery
We deliver to the address you provide. Nairobi CBD is often same-day on business days.
Nairobi CBD or Kenya-wide
Free CBD ≥ KES 20,000; else from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Lightwave LC-LC SM Duplex Fiber Cord
The Lightwave LC UPC Patch Cord provides high-density connectivity for enterprise-grade networking environments requiring reliable single-mode fiber transmissions. This 1-meter optical assembly utilizes premium ceramic ferrules to ensure precise alignment and minimal signal degradation across the link. Consequently, it supports high-speed data applications including Gigabit Ethernet and Fiber Channel within data centers and telecommunication rooms. The duplex configuration allows for simultaneous bidirectional data flow, which is essential for modern switch-to-server or switch-to-switch interconnects. Furthermore, the cable construction adheres to strict industry standards for attenuation and return loss.
Key Features
LC UPC Connectors
The Small Form Factor (SFF) connectors utilize 1.25mm ceramic ferrules for high-density patching environments.OS2 Single Mode Performance
- Optimized for 9/125 micron fiber cores.
- Supports long-haul transmission with minimal pulse dispersion.
- Compliant with G.652.D fiber specifications.
LSZH Outer Jacket
Low Smoke Zero Halogen material ensures safety by reducing toxic and corrosive gas emissions during combustion.
Specifications of Lightwave LC UPC Patch Cord
| Feature | Specification |
|---|---|
| Connector Type | LC UPC to LC UPC |
| Fiber Mode | Single Mode (OS2) |
| Core/Cladding | 9/125 µm |
| Strand Count | Duplex (2 Strands) |
| Length | 1 Meter |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 50 dB |
| Jacket Diameter | 2.0 mm |
What’s in the Box
- 1 x Lightwave 1M LC-LC Single Mode Duplex Patch Cord
- Individual Test Report Data
- Protective Dust Caps
Why Choose This Fiber Cable
- Enhanced signal integrity is maintained through Ultra Physical Contact (UPC) polishing which minimizes back-reflection.
- The 1-meter length is specifically engineered for cross-connects within standard 19-inch racks to prevent excessive slack.
- Durability is verified through rigorous pull-tension and radius bend testing to ensure long-term mechanical stability.
- The yellow jacket provides immediate visual identification of single-mode media within mixed-cabling environments.
- Compliance with international standards ensures compatibility with SFP and SFP+ transceivers from various manufacturers.
