HP Spectre 13-AW Gold Full Display Assembly 13.3-inch FHD IPS Touch 30-Pin eDP

Gold-Finish Top Half Replacement

The HP Spectre 13-AW Gold Assembly is a complete top-half display module for the Spectre x360 13-AW convertible series, supplied in the original gold finish to match the chassis. It bundles the LCD panel, capacitive digitizer, bezel, lid and hinges into one drop-in part. Technicians replace the whole upper section rather than separating bonded glass from the panel.

The 13.3-inch panel runs 1920 x 1080 at 60 Hz with IPS viewing angles of 178 degrees. Pixel density reaches about 166 PPI and the finish carries an anti-reflective coating with Gorilla Glass NBT protection. Colour coverage hits 100 percent sRGB on the FHD variant. The assembly connects through a 30-pin eDP harness on FHD models; 4K and OLED variants use a 40-pin connector.

Touch input supports 10-point capacitive multi-touch and active stylus operation, restoring tablet, tent, stand and laptop modes after repair. The module fits 13-aw0000, 13-aw1000 and 13-aw2000 sub-series once panel grade and finish match the original unit. Factory hinge brackets are pre-fitted and the lid opens from closed to the original stop angle.

Key Features

• Complete Gold Top Assembly
  The module ships with the LCD, digitizer, bezel, lid and hinges pre-assembled in the original gold finish.
• FHD IPS Touch Panel
  • 1920 x 1080 resolution at 60 Hz
  • IPS technology with 178-degree viewing angles
  • 10-point capacitive multi-touch and stylus support
• eDP Connector Options
  FHD panels use a 30-pin eDP connector, while 4K OLED variants require the 40-pin harness.
• Anti-Reflective Gorilla Glass
  The front glass carries an anti-reflection treatment and Corning Gorilla Glass NBT protection.
• Sub-Series Compatibility
  The assembly fits Spectre x360 13-aw0000, 13-aw1000 and 13-aw2000 models when the panel grade and finish match.
• Pre-Fitted Hinges and Cable
  Hinge brackets and the display cable arrive installed, which reduces bench time during depot or on-site repair.

Specifications

What’s in the Box

• HP Spectre 13-AW gold display assembly
• Pre-fitted bezel, digitizer, hinges and display cable
• Protective packaging

Why Choose the Spectre 13-AW Assembly

• The gold finish matches the original lid and keyboard deck without repainting or colour mismatch.
• Replacing the full hinge-up section avoids adhesive rework on a bonded glass panel.
• The 13.3-inch FHD IPS module preserves battery runtime compared with the 4K OLED option on the same chassis.
• Pre-installed hinges and cable cut installation time for repair desks and fleet maintenance teams.
• 10-point touch and active pen support restore convertible modes after a cracked or unresponsive panel.
