Hikvision DS-7204HGHI-K1 4-Channel 1080p Turbo HD DVR
WhatsApp for availability
Hikvision 4-Channel 1080p Turbo HD DVR
| Feature | Specification |
|---|---|
| Channels | 4-ch Analog + 1-ch IP |
| Max Resolution | 1080p Lite @ 15fps |
| Compression | H.265 Pro+ |
| Storage | 1 SATA (Up to 4TB) |
| Signal Support | TVI/AHD/CVI/CVBS |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
DS-7204HGHI-K1 Turbo HD DVR
The Hikvision 4-Channel Turbo DVR provides a reliable backbone for analog surveillance systems requiring high-definition recording. This device utilizes H.265 Pro+ video compression to optimize bandwidth and storage consumption. Engineers can integrate four high-definition analog cameras along with an additional IP input. The system automatically detects HDTVI, AHD, CVI, and CVBS signals upon connection. This eliminates the need for manual channel configuration during setup. Users achieve 1080p Lite resolution at 15 frames per second across all channels. The hardware supports long-distance transmission over coaxial cable. Users can expect signal stability up to 1200 meters for 720p HDTVI signals.
The recording unit features a single SATA interface for internal storage. It accommodates hard drives with capacities up to 4 TB. This capacity provides sufficient space for multi-week retention periods when using modern encoding standards. The H.265 Pro+ codec reduces file sizes by up to 75% compared to standard H.264. This efficiency allows for longer archives without upgrading physical disk arrays. The rear panel includes HDMI and VGA outputs for local monitoring. Both outputs support resolutions up to 1920 x 1080.
Remote monitoring remains a core function of this surveillance hub. The RJ45 Ethernet port facilitates connection to the local network. Administrators manage the device via Hik-Connect or DDNS services. This allows for mobile viewing and configuration from remote locations. The software interface provides tools for playback, motion detection, and alarm notifications. Two USB 2.0 ports permit mouse control and data export to external drives. Additionally, the system supports one IP camera input to complement the four analog channels.
The chassis maintains a compact footprint for installation in cramped equipment racks. Passive cooling ensures quiet operation in office environments. The 12 VDC power supply maintains low energy consumption during continuous operation. This unit serves as a cost-effective upgrade path for legacy analog systems. It bridges the gap between older coax infrastructure and modern digital imaging.
Key Features
Adaptive Signal Input
The hardware automatically recognizes HDTVI, AHD, CVI, and CVBS signals without manual software adjustments.Advanced Video Compression
- H.265 Pro+ improves encoding efficiency by up to 75%
- Reduces storage costs while maintaining 1080p image quality
Hybrid Channel Expansion
One additional IP channel allows for a total of five camera inputs using existing network infrastructure.Long-Distance Transmission
- Supports up to 1200m for 720p HDTVI signals
- Supports up to 800m for 1080p HDTVI signals
Specifications
| Feature | Specification |
|---|---|
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Analog Video Input | 4-ch BNC (1.0 Vp-p, 75 Ω) |
| IP Video Input | 1-ch (up to 5-ch) up to 1080p resolution |
| Encoding Resolution | 1080p lite/720p/WD1/4CIF/VGA/CIF |
| HDMI/VGA Output | 1-ch, 1920 × 1080/60Hz |
| SATA Interface | 1 SATA interface up to 4 TB capacity |
| Network Interface | 1, RJ45 10M/100M self-adaptive Ethernet |
What’s in the Box
Hikvision DS-7204HGHI-K1 DVR
Power Supply Adapter
USB Wired Mouse
SATA Data and Power Cables
Quick Start Guide
Why Choose DS-7204HGHI-K1
High efficiency encoding reduces bandwidth requirements for mobile viewing applications and remote monitoring.
Universal signal support allows for seamless integration of legacy analog and modern high-definition cameras.
Compact thermal design ensures long-term hardware stability in standard residential or commercial enclosures.
