Front Runner TRBU003 Pickup Load Bed Tracks 1400mm – Black Powder-Coated Aluminium Pair

Low-Profile Rails for Pickup Bed Rack Mounting

The Front Runner load bed tracks add two low-profile rails to a pickup bed that has no factory track. Each rail measures 1468 mm long, 51 mm wide and 16 mm high. The pair weighs 1.49 kg with the fixing plates in place.

Front Runner extrudes the rails from aluminium and finishes them in black powder coat. Six 3CR12 stainless steel fixing plates bolt the rails to the bed floor. Rubber strips sit under each rail to protect the paint, and plastic end caps close the channel at both ends.

The channel accepts Front Runner Load Bed Legs, which slide in or out so a Slimline II rack or load bars come off without tools. Fitment covers load beds measuring 1762 mm to 1964 mm. Beds without factory mounting points need drilling.

Measure the bed before ordering and check that the rail position clears the wheel arches and tailgate. Seal each drill hole with a suitable sealant and torque the fixing plates evenly. Re-check the bolts after the first loaded trip.

A rack over the bed frees the floor for cargo while keeping recovery gear, fuel and camping equipment off the load surface. The low 36 mm stack height with plates fitted leaves clearance under a tonneau or canopy. Confirm that clearance before drilling.

Wipe the rails with a damp cloth and clear grit from the channel before sliding the legs. Touch up stone chips on the powder coat to limit corrosion. Inspect the fixing plates at each service interval and replace any plate that shows deep pitting.

Key Features

• Black Powder-Coated Aluminium Rails
  Two extruded rails carry a powder coat that resists scuffs and road salt.

• Complete Mounting Kit

  • Two aluminium tracks and two rubber tracks
  • Four plastic end caps
  • Six black powder-coated 3CR12 stainless steel fixing plates
  • Installation hardware included

• Slide-In Leg Interface
  Load Bed Legs slide along the channel to position a rack or load bars.

• Tool-Free Rack Removal
  The rack comes off the vehicle by sliding the legs out of the track.

• Low 16 mm Rail Height
  The rail sits close to the bed floor and rises to 36 mm with the plates fitted.

• Paint Protection Strips
  Rubber strips sit between each rail and the bed surface.

• Rack and Bar Compatibility
  The tracks take an appropriately sized Slimline II tray or Front Runner load bars.

Specifications

What’s in the Box

• 2 x aluminium tracks

• 2 x rubber tracks

• 4 x plastic end caps

• 6 x black powder-coated 3CR12 stainless steel fixing plates

• Installation hardware

Why Choose This Track Pair

• The rails give a pickup without factory tracks a proper rack mounting point.

• The stainless fixing plates resist corrosion where water collects on the bed floor.

• A 36 mm stack height keeps clearance under canopies and tonneau covers.

• The slide-in channel lets one person remove a loaded rack before a tip run.

• Rubber strips protect the bed paint during fitment and daily use.
