Fanvil H4 IP Phone (Black) — 2 SIP Lines, PoE, HD Voice

Hospitality SIP Handset for Guest Rooms

The Fanvil H4 IP phone is a two-line SIP handset built for hotel guest rooms, service corridors and front-desk overflow. It combines wideband audio with a 10/100 Mbps Ethernet port and 802.3af Power over Ethernet. Five programmable keys map directly to reception, housekeeping and emergency services.

Two SIP accounts let the unit hold concurrent calls, while ten speed-dial keys give guests one-touch access to routine services. G.722 and Opus wideband codecs run alongside narrowband G.711A/U, G.729AB, G.723.1, G.726 and iLBC for interoperability with legacy PBX trunks. Full-duplex handsfree operation adds acoustic echo cancellation, voice activity detection and automatic gain control.

A USB-A port charges handsets and tablets without a separate adapter. Power draw spans 0.66 W to 4.07 W over PoE and 0.85 W to 5.5 W from an optional 5 V 2 A supply. The desk stand measures 221 x 127.5 x 70.5 mm, and the front panel accepts printed customisation for property branding. Operating range covers 0 °C to 45 °C at 10% to 95% relative humidity.

Key Features

• Five Programmable DSS Keys
  Each key carries a user-defined number and icon for reception, room service or emergency escalation.

• Ten One-Touch Speed Dial Keys
  Guests reach frequent services with a single press instead of dialling full extensions.

• Wideband Voice Path
  16 kHz sampling with G.722 and Opus delivers clear intelligible speech on both handset and speakerphone.

• Network and Deployment Options

  • 802.3af PoE removes the need for a local power outlet at each room
  • IPv4, IPv6 and dual-stack modes with static, DHCP or PPPoE addressing
  • VLAN 802.1P/Q, LLDP, 802.1X and L2TP/OpenVPN tunnelling
  • Auto-provisioning via FTP, TFTP, HTTP, HTTPS, DHCP option 66, SIP PnP and TR-069

• USB Charging Port
  A front-facing USB-A socket powers guest devices without an extra wall charger.

Specifications

What’s in the Box

• Fanvil H4 handset and base

• RJ9 coiled handset cord

• 1.5 m CAT5 Ethernet cable

• Desk stand

• Quick installation guide

Why Choose Fanvil H4

• Single-cable installation through 802.3af PoE cuts cabling labour and wall-socket hardware per room.

• TR-069 and DHCP option 66 provisioning let engineers stage hundreds of extensions from one template.

• Dual SIP registration supports a guest line plus a management or emergency line on the same chassis.

• Open SIP firmware with OpenVPN and VLAN tagging integrates with existing IP-PBX and hospitality middleware.
