Dahua LCH86-MC410-B-S2 86″ 4K Smart Interactive Whiteboard with 48MP AI Camera
Original price was: KSh 341,200.00.KSh 282,000.00Current price is: KSh 282,000.00. ex VAT
Dahua LCH86-MC410-B-S2 86″ 4K Smart Interactive Whiteboard with 48MP AI Camera
| Feature | Specification |
|---|---|
| Screen Size | 86 inch |
| Resolution | 3840 × 2160 (4K UHD) |
| Panel | DLED, 350 cd/m², 60 Hz |
| Operating System | Android 14 |
| CPU / GPU | Quad-core A55 1.9 GHz / Mali-G52 MP2 |
| Memory | 8 GB RAM, 64 GB ROM |
| Touch | Infrared, 32 points (Android), ≤5 ms |
| Camera | 48 MP AI, 2560 × 1440 @ 30 fps |
| Microphone | 8-array, 12 m pickup |
| Wireless | Wi-Fi 6 dual-band, Bluetooth 5.2 |
| Audio | 2 × 15 W, 2.0 channel |
| Power | 100–240 VAC, 340 W max |
| Mounting | 800 × 400 mm wall bracket |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
86-inch Collaboration Display
The Dahua 4K interactive whiteboard pairs an 86-inch DLED panel with infrared touch and an embedded Android 14 module. It renders 3840 × 2160 at 60 Hz and registers finger or stylus input across 32 simultaneous contact points. Annotation, whiteboarding and video calls share one surface without an attached PC.
A quad-core A55 processor at 1.9 GHz, ARM Mali-G52 MP2 GPU, 8 GB RAM and 64 GB ROM run the built-in system. The 48 MP AI camera works with an eight-microphone array rated for 12 m pickup. Wi-Fi 6 drives station and access point radios concurrently, and Bluetooth 5.2 connects keyboards and peripherals.
The panel draws 182 W in typical operation and 340 W at peak from a 100–240 VAC supply, with standby below 0.5 W. A metal chassis carries 3.2 mm anti-dazzle tempered glass at ≥9H hardness. Operating range runs 0 °C to 40 °C at 10–90% RH non-condensing.
Key Features
Infrared Multi-Touch Surface
Android reports 32 touch points and Windows reports 40, with ≤5 ms response and 2 mm object recognition over 90% of the active area.Dual-Platform Operation
- Android 14 runs natively on the embedded module.
- Windows 7/8/10/11 runs through the plug-in PC module slot.
- A Type-C IN port passes the camera and microphone to a connected laptop for BYOM sessions.
48 MP AI Camera and 8-Mic Array
The sensor captures 48 MP stills on Android and 2560 × 1440 video at 30 fps with an 88° diagonal field of view. The array adds automatic gain control, echo cancellation and omnidirectional pickup.Wireless Casting and Dual-Band Radios
The bundled plug-in module mirrors screens from phones, tablets and laptops while 2.4 GHz and 5 GHz hotspot modes stay active alongside the station link.Conference Audio
Two front-facing 15 W cavities deliver 2.0-channel output across 150 Hz–20 kHz.Mounting Hardware
The 800 × 400 mm hole pattern suits the supplied wall bracket or a mobile trolley, and the panel weighs 68 kg net.
Specifications
| Feature | Specification |
|---|---|
| Screen Size | 86 inch |
| Backlight | DLED |
| Resolution | 3840 × 2160 |
| Aspect Ratio | 16:9 |
| Brightness | 350 cd/m² (typ.) |
| Contrast Ratio | 1200:1 (typ., IPS) |
| Viewing Angle | H: 178°, V: 178° |
| Refresh Rate | 60 Hz |
| Display Response | ≤8 ms |
| Colour Gamut | ≥72% NTSC |
| Panel Lifespan | ≥50,000 hours |
| Touch Technology | Infrared |
| Touch Points | Android 32 / Windows 40 |
| Touch Response | ≤5 ms |
| Valid Touch | 2 mm over 90% of area |
| Protective Glass | 3.2 mm anti-dazzle tempered, ≥9H |
| Operating System | Android 14 |
| CPU | Quad-core A55, 1.9 GHz |
| GPU | ARM Mali-G52 MP2 (2EE) |
| Memory | 8 GB RAM / 64 GB ROM |
| External OS Support | Windows 7/8/10/11 (PC module) |
| Camera | 48 MP AI (Android), 2560 × 1440 @ 30 fps |
| Microphone | 8-array, 8–12 m pickup, AGC and AEC |
| Speakers | 2 × 15 W, 150 Hz–20 kHz |
| Wi-Fi | Wi-Fi 6, station + AP, 2.4/5 GHz |
| Bluetooth | BR/EDR/BLE 5.2 |
| Video Input | 2 × HDMI 2.0 (4K@60 Hz) |
| USB | 1 × USB 3.2 Gen1 Type-A, 2 × USB 2.0 Type-A, 1 × Micro USB 2.0 |
| Other Ports | 1 × RJ-45, 1 × RS-232 (DB9), 1 × Type-C (USB 2.0 + 5 W), 1 × 3.5 mm line out |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Power Consumption | 182 W basic / 340 W max |
| Standby Power | ≤0.5 W |
| Operating Temperature | 0 °C to +40 °C |
| Operating Humidity | 10%–90% RH, non-condensing |
| Dimensions | 1953.8 × 115.7 × 1177.2 mm |
| Net Weight | 68 kg |
| Mounting | 800 × 400 mm, wall bracket or mobile stand |
What’s in the Box
Smart interactive whiteboard
Wireless plug-in module
Power cord
2 × stylus pen
Wall mount bracket and accessory package
Remote control
Quick start guide and regulatory information
Why Choose Dahua
The infrared layer holds handwriting latency at ≤5 ms and recognises 2 mm objects for fine annotation.
Android and Windows paths share one screen, so legacy applications and web tools coexist on the same panel.
The 48 MP sensor and 12 m pickup distance cover medium and large meeting rooms without external AV hardware.
Wi-Fi 6 radios and a Type-C BYOM port cut cabling in hybrid meeting spaces.
A metal casing and 3.2 mm tempered glass withstand daily classroom and boardroom handling.
