CAM CONNECT Camera Connectivity Adapter with BNC and DC Power Terminals

Camera Signal and Power Interface for CCTV Installations

The CAM CONNECT provides a direct interface between surveillance cameras and coaxial cabling runs. It combines a BNC video terminal with a screw-terminal DC power pair in a single inline module. Technicians use it to terminate camera drops without separate video and power connectors.

The BNC port accepts standard 75-ohm coaxial cable and mates with male BNC plugs on camera pigtails or DVR inputs. The DC side exposes two screw terminals for 12 V DC or 24 V AC power pairs. A moulded ABS housing insulates the conductors and strain-relieves both cable entries.

The module measures 45 × 22 × 18 mm and weighs 28 g. It operates across -10°C to +55°C and suits indoor ceiling voids, back boxes and camera housings. The screw terminals accept 18–24 AWG conductors, and the BNC centre pin and shield contact use gold-plated brass.

Key Features

• Combined Video and Power Interface
  A single inline module carries BNC video and a two-pole DC power pair through one compact housing.

• BNC Coaxial Terminal

  • 75-ohm characteristic impedance for composite CCTV video.
  • Gold-plated centre pin and shield contact resist oxidation.
  • Mates with standard male BNC plugs on camera and DVR leads.

• Screw-Terminal Power Pair
  Two captive screws clamp 18–24 AWG conductors for 12 V DC or 24 V AC camera feeds.

• Moulded ABS Housing
  The insulated body measures 45 × 22 × 18 mm and provides strain relief at both cable entries.

• Field-Terminable Design
  Installers assemble the module with a small flat-blade screwdriver and a coaxial stripping tool.

• Compact Inline Form Factor
  The 28 g body fits inside standard back boxes and camera housings without extra mounting hardware.

• Wide Power Compatibility
  The two-pole terminal block accepts both 12 V DC and 24 V AC feeds used by analogue and HD cameras.

Specifications

What’s in the Box

• Inline camera adapter

• Installation leaflet

Why Choose This Inline Adapter

• Reduces connector count at each camera drop by combining video and power in one module.

• Field-terminable screw terminals and a standard BNC interface suit retrofit and new cabling.

• Compact ABS body fits inside back boxes and camera housings.

• Gold-plated contacts maintain signal integrity across repeated mating cycles.

• Handles 12 V DC and 24 V AC camera power without separate adapters.

• Strain-relieved cable entries protect terminations in ceiling voids and outdoor housings.
