Bixolon Wax Ribbon 110mm x 74m Black CSO 12mm Core for SLP-TX400

Thermal Transfer Consumable for Desktop Label Printers

The Bixolon Wax Ribbon 110mm is a black thermal transfer ribbon supplied on a 12 mm core for 4-inch desktop label printers. It measures 110 mm wide and 74 m long, which matches the ribbon bay on the SLP-TX400 and TX420 chassis. The wax formulation transfers at low energy and produces sharp barcodes on coated and uncoated paper stocks.

Winding direction is coated-side-out, so the inked face meets the label as the ribbon passes the printhead. Total thickness measures about 7.8 µm, split between a 4.8 µm PET base film and a 3.0 µm ink layer. The wax melts near 70 °C, which keeps printhead energy demand low at speeds up to 8 ips.

The 74 m roll suits low to medium print volumes and fits compact desktop models that cannot take 300 m or 450 m spools. Compatible Bixolon units include the SLP-TX400, SLP-TX420, SLP-TX423, XD3-40, XD5-40t, XD5-40tR and XD5-43t. The same ribbon also runs in Zebra GK420t, GC420t, GX420t and TLP2844 printers. Operating range is 5 °C to 35 °C, and the assembly carries RoHS compliance.

Key Features

• Wax Thermal Transfer Formulation
  The wax ink layer melts at roughly 70 °C and bonds to coated and uncoated paper labels without high printhead energy.

• 110 mm x 74 m Roll Geometry

  • 110 mm width matches 4-inch desktop printheads and media paths
  • 74 m length suits compact printers with limited ribbon bays
  • 12 mm core diameter seats on standard spindle hubs

• Coated-Side-Out Winding
  The ink faces outward so it contacts the label surface directly as the ribbon advances past the printhead.

• Sharp Barcode and Text Output
  The 3.0 µm ink layer holds edge definition on 1D barcodes, 2D codes and small-point text at 203 and 300 DPI.

• Scratch and Smudge Resistance
  Printed labels resist routine abrasion from handling, carton movement and shelf contact.

• Broad Printer Compatibility
  The roll runs in Bixolon SLP-TX and XD series units plus Zebra G-series and TLP2844 thermal transfer models.

Specifications

What’s in the Box

• Bixolon wax ribbon, 110 mm x 74 m, black, 12 mm core

• Protective wrap

Why Choose This Bixolon Roll

• The 74 m spool fits compact desktop bays that reject 300 m and 450 m rolls.

• Low melt temperature cuts printhead energy and extends head life on high-duty cycles.

• CSO winding removes the guesswork when loading ribbon into Bixolon and Zebra chassis.

• The 110 mm width covers full 4-inch label stock without edge waste.

• Black wax output stays legible on shipping cartons and retail shelf tags.
