8G Self Tapping Screws 1/4 Inch Pan Head Pozi Zinc Plated Steel

Short Pan Head Fasteners for Sheet Metal and Plastic

The 8G Self Tapping Screws are 1/4 inch pan head fasteners with a Pozi drive and a bright zinc plated finish. Each screw measures 4.2 mm across the thread and 6.35 mm under the head. Installers use them for rack blanks, plastic enclosures and light sheet metal assemblies.

The Type AB gimlet point starts in a pre-drilled pilot hole and cuts its own matching thread. Thread pitch measures 1.4 mm with an 8-18 thread count. The pan head spreads clamping load over an 8.2 mm diameter and stands 3.05 mm above the surface. A PZ2 bit drives the recess without cam-out at normal torque.

Cold-formed steel gives the screw enough hardness to cut into mild sheet without snapping. The zinc plating resists surface corrosion in dry indoor conditions. These fasteners suit blanking panels, bracket fixing, plastic housings and light woodwork. Length is measured from under the head, so a 6.35 mm screw grips roughly 5 mm of material after the point engages.

Key Features

• Type AB Gimlet Point
  The sharp point starts in a pilot hole and forms a matching thread as it drives.

• Pan Head Profile

  • 8.2 mm head diameter spreads clamp load
  • 3.05 mm head height stays low against panels
  • Flat bearing face seats on washers and brackets

• Pozi PZ2 Drive
  The four-lobe recess accepts a standard PZ2 bit and limits driver slip at moderate torque.

• Zinc Plated Steel
  Bright zinc plating protects the steel body from surface rust in indoor installations.

• 8-18 Thread Form
  The 1.4 mm pitch cuts cleanly into mild steel, aluminium and rigid plastic.

• Short 1/4 Inch Length
  The 6.35 mm under-head length suits thin panels and shallow plastic bosses.

• Bulk Supply
  The carton holds 1,000 pieces for panel builds and repeat maintenance work.

Specifications

What’s in the Box

• 1,000 zinc plated 8G x 1/4 inch pan head self-tapping screws

Why Choose These Fasteners

• The short under-head length suits blanking panels and thin plastic housings.

• The Type AB point cuts its own thread in a drilled pilot hole.

• Pozi drive transfers torque without rounding the recess.

• Zinc plating holds up in dry indoor racks and cabinets.

• A 1,000-piece carton covers large panel builds and spare stock.
