2000W 48V Horizontal Wind Turbine M-Type 1.08m Blades Off-Grid

Horizontal-Axis Generator for Off-Grid DC Bus Charging

The 2000W 48V wind turbine is an M-type horizontal-axis generator that feeds a 48 V DC bus directly. Three 1.08 m nylon-fibre blades turn a 2.3 m rotor at a 2.5 m/s cut-in speed. A three-phase permanent-magnet alternator converts rotation without brushes or slip rings.

Rated output reaches 2000 W at 12 m/s wind speed, with a 2500 W peak. The generator housing carries an IP54 rating for dust and splash protection. Electromagnetic braking provides overspeed control, and an automatic yaw rudder aligns the rotor with changing wind direction.

The turbine weighs 45 kg and mounts on a flange seat that accepts a standard steel tower. Operating temperature spans -40°C to 80°C, and the unit survives wind speeds up to 45 m/s. The nylon-fibre blades resist fatigue under cyclic loading. A separate charge controller is required to regulate the 48 V output and manage dump loads.

Key Features

• Three-Phase Permanent-Magnet Alternator
  A brushless PM generator reduces maintenance and delivers power from low rotor speeds.

• M-Type Blade Geometry
  Precision-moulded nylon-fibre blades use an optimised aerodynamic profile for high wind-energy capture.

• Electromagnetic Overspeed Brake

  • The controller applies electromagnetic braking when rotor speed exceeds safe limits.
  • Manual braking remains available for maintenance and storm preparation.
  • Braking protects the alternator and blades during gusts above 45 m/s.

• Automatic Yaw Alignment
  A tail rudder rotates the nacelle to face incoming wind without manual adjustment.

• IP54 Generator Enclosure
  The housing seals against dust ingress and water splashes from rain or spray.

• Low 2.5 m/s Cut-In Speed
  The rotor starts producing usable voltage in light breezes common to inland sites.

• Flange Tower Mounting
  The cast flange seat bolts to a steel pipe tower and simplifies nacelle installation.

Specifications

What’s in the Box

• Wind turbine nacelle and rotor assembly

• Three nylon-fibre blades

• Tail rudder and mounting hardware

Why Choose This M-Type Turbine

• The 48 V DC output matches common off-grid battery banks and hybrid inverter inputs.

• A 2.5 m/s cut-in extends generation into low-wind mornings and evenings.

• The PM alternator avoids brush wear and needs no field excitation.

• Electromagnetic braking adds an automatic overspeed layer for exposed sites.

• At 45 kg, the nacelle suits two-person installation on a modest tower.

• IP54 sealing handles dusty inland conditions and coastal spray.
