Siemon Z-MAX 48-Port Category 6A Shielded Patch Panel 1U
Original price was: KSh 77,586.21.KSh 62,068.97Current price is: KSh 62,068.97. ex VAT
Siemon Z-MAX 48-Port Category 6A Shielded Patch Panel 1U
| Feature | Specification |
|---|---|
| Ports | 48 |
| Category | 6A Shielded |
| Height | 1U |
| Termination | Z-MAX Modular |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
Siemon Z-MAX 48-Port Panel
The Siemon Z-MAX Shielded Panel provides high-density 10Gb/s performance within a standard 1U rack mount space. This solution doubles the density of traditional 24-port panels to conserve valuable cabinet real estate. It utilizes a modular design based on Siemon Z-MAX 6A shielded outlets to ensure superior Alien Crosstalk suppression. The panel construction uses high-strength cold rolled steel with a black finish for durability in data center environments. Every port features a diagonal orientation to optimize space and improve cable management efficiency. This hardware supports advanced network applications including 10GBASE-T and high-power PoE delivery.
Key Features
High-Density 1U Configuration
This panel houses 48 ports in a single rack unit to maximize space utilization in congested server racks.Quick-Ground Technology
Integrated grounding paths automatically connect shielded outlets to the panel ground plane during installation.Z-MAX Termination Efficiency
- Linear lacing process eliminates pair untwisting for consistent electrical performance.
- Termination tool ensures uniform contact pressure across all 48 ports.
- Outlets provide 360-degree shielding to mitigate electromagnetic interference.
Enhanced Cable Management
The included rear cable manager supports heavy bundles while maintaining the proper bend radius for Category 6A media.
Specifications
| Feature | Specification |
|---|---|
| Port Count | 48 Ports |
| Performance Category | Category 6A / Class EA |
| Shielding Type | Shielded (S/FTP, F/UTP) |
| Rack Units | 1U (1 RMS) |
| Material | Cold Rolled Steel (Black) |
| Grounding | Quick-Ground Integrated System |
| Compliance | TIA-568.2-D, ISO/IEC 11801-1 |
What’s in the Box
48-Port 1U Shielded Patch Panel
48 Z-MAX 6A Shielded Outlets
Rear Cable Management Tray
Grounding Lug and Hardware
Installation Instructions
Why Choose Siemon Z-MAX 48-Port Panel
The high-density layout reduces the number of rack units required for large-scale 10GBASE-T deployments.
Diagonal port orientation reduces the risk of Alien Crosstalk by increasing physical distance between adjacent pairs.
Stainless steel spring clips ensure a permanent grounding path without manual bonding for every individual port.
Additionally, the modular design allows for rapid replacement or reconfiguration of individual ports without disturbing adjacent connections.
The system supports Power over Ethernet Type 4 (90W) with minimal heat buildup due to robust contact design.
