NETGEAR GSM4212PX-100EUS M4250-10G2XF-PoE+Switch
The NETGEAR GSM4212PX-100EUS, part of the M4250 AV Line Series, is an enterprise-grade Layer 2/Layer 3 managed switch engineered specifically for modern audio-visual over IP (AVoIP) environments. Designed with a dedicated AV-friendly web-based GUI, the switch simplifies deployment for Dante, Q-SYS, AES67, NDI, NVX, and other advanced AV transport technologies.
Key Features
-
AV-Centric GUI & Configuration Profiles
Purpose-built interface with color-coded AV profiles optimized for Dante, Q-SYS, AES67, AVB, NDI, NVX, and SVSI traffic. -
Comprehensive AV Protocol Support
Supports Dante, AES67, Q-SYS audio, AVB (with licensed upgrade), and multiple video-over-IP platforms. -
Flexible Mixed Profiles
Configure audio, video, and control traffic simultaneously with optimized QoS and multicast behavior. -
Automatic Network Optimization
NETGEAR IGMP Plus ensures immediate multicast stability without advanced configuration. -
10G Uplink Capability
Includes (2) 10G SFP+ uplink ports for high-capacity backbone links and aggregation. -
Powerful PoE+ Delivery
8 PoE+ ports with 30W each and 240W total budget — ideal for IP cameras, AV devices, and APs. -
Advanced L2/L3 Switching Architecture
Offers static routing, RIP, PIM multicast routing, DHCP Server, and PTPv2 timing compatibility. -
Enterprise-Grade Security
Supports RADIUS, ACLs, DHCP snooping, MAC authentication, SSH/SSL, BPDU protection, and loop prevention. -
Robust Hardware Design
1U rack-mountable metal chassis with low acoustic noise (39.2 dB), designed for professional AV racks.
Specifications
| Feature | Specification |
|---|---|
| Model | NETGEAR GSM4212PX-100EUS (M4250-10G2XF-PoE+) |
| Switch Type | Managed |
| Switching Layer | L2 / L3 |
| Ethernet Ports | 10 × Gigabit RJ45 |
| PoE/PoE+ Ports | 8 × PoE+ (30W each) |
| Total PoE Budget | 240W |
| Uplink Ports | 2 × SFP+ (10G) |
| Additional SFP Slots | 2 |
| Switching Capacity | 60 Gbps |
| Throughput | 44.64 Mpps |
| MAC Address Table | 16,000 entries |
| Buffer Memory | 16 MB |
| Jumbo Frames | Up to 12,000 bytes |
| Processor | ARM Cortex-A9, 1.25 GHz |
| Internal Memory | 2048 MB |
| AV Protocol Support | Dante, AES67, Q-SYS, AVB (license), NDI, NVX, SVSI |
| Networking Standards | IEEE 802.1D / 802.1Q / 802.1x / 802.3ad / 802.3af / 802.3at / 802.3bt |
| VLAN Support | 4093 VLANs (MAC, Protocol, Voice, Private VLAN) |
| Routing Support | Static, RIP, PIM |
| DHCP | DHCP Server, Relay, Snooping (IPv4 & IPv6) |
| Security Features | ACLs, RADIUS, MAC Authentication, DHCP Guard, SSH/SSL |
| IGMP Snooping | Yes (with IGMP Plus) |
| Noise Level | 39.22 dB |
| Form Factor | 1U Rack Mount |
| Dimensions | 440 × 200 × 43.2 mm |
| Weight | 2.96 kg |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 70°C |
| Operating Humidity | 0–90% |
| Heat Dissipation | 1046 BTU/hr |
| MTBF | 947,871 hours |
| HS Code | 85176990 |
What’s in the Box
-
1 × NETGEAR GSM4212PX-100EUS M4250 Managed Switch
-
1 × Rack Mount Kit
-
1 × Power Cable
-
Installation Guide & Documentation
Why Choose the M4250-10G2XF-PoE+
-
Purpose-built for professional AV over IP deployments
-
Simplified AV system setup using dedicated AV profiles
-
High-performance Gigabit + 10G hybrid design
-
PoE+ power delivery for AV equipment, cameras, and access points
-
Excellent multicast performance with IGMP Plus
-
Advanced security and routing for enterprise-grade reliability
-
Low noise, rack-ready hardware ideal for studios & auditoriums
