Mercury MP Pro 6k S 6KVA/6KW Online UPS PF 1.0
Original price was: KSh 198,000.00.KSh 189,500.00Current price is: KSh 189,500.00. ex VAT
Mercury MP Pro 6k S 6KVA/6KW Online UPS PF 1.0
| Feature | Detail |
|---|---|
| Capacity | 6KVA / 6KW (PF 1.0) |
| Type | Online Double Conversion |
| Battery | 20 x 9AH/12V (±120VDC) |
| Connectivity | RS232 & USB |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
Mercury MP Pro 6k S
The Mercury 6KVA Online UPS provides a high-density power protection solution with a unity power factor of 1.0, delivering 6KW of actual power capacity. This system utilizes true online double-conversion technology to ensure complete electrical isolation between the input utility and the connected load. Consequently, the unit eliminates all power disturbances, including surges, spikes, and frequency variations. The architecture features a 1/1 phase configuration, making it compatible with standard single-phase infrastructure while supporting high-demand server environments. Therefore, the device maintains a pure sine wave output with zero millisecond transfer time during power transitions.
Key Features
-
Unity Power Factor
The 1.0 PF rating ensures that the output wattage equals the VA rating, providing 100% real power for modern PFC-corrected power supplies. -
Advanced Battery Management
- Operates on a ±120VDC bus voltage for efficient DC-to-AC inversion.
- Includes twenty internal 12V/9AH batteries for extended runtime.
- Features intelligent charging algorithms to prolong battery service life.
-
Communication and Control
Integrated RS232 and USB ports allow for comprehensive local monitoring and automated shutdown sequences. -
Robust Industrial Interface
- Utilizes dedicated input and output terminal blocks for secure hardwired connections.
- Supports wide input voltage windows to reduce battery discharge cycles.
- Includes an internal bypass mechanism for fault tolerance and maintenance.
Specifications
| Feature | Specification |
|---|---|
| Capacity | 6000VA / 6000W |
| Topology | Online Double Conversion |
| Power Factor | 1.0 |
| Input/Output Phase | Single Phase (1:1) |
| Battery Configuration | 20 x 12V/9AH |
| Nominal DC Voltage | ±120VDC |
| Communication Ports | USB, RS232 |
| Connection Type | Terminal Block Input/Output |
What’s in the Box
-
Mercury MP Pro 6k S Online UPS Unit
-
USB Communication Cable
-
RS232 Serial Cable
-
User Manual and Technical Documentation
Why Choose This Power Solution
-
The unity power factor design maximizes efficiency by eliminating wasted reactive power in the circuit.
-
Double conversion topology protects sensitive networking hardware from total harmonic distortion and voltage fluctuations.
-
The high-capacity battery string provides significant bridge time during extended utility outages.
-
Hardwired terminal connections ensure high-current reliability for critical data center infrastructure.
