Lightwave SC-SC Duplex OM2 Patch Cord
The Lightwave SC-SC Duplex MM 3-meter patch cable provides reliable high-bandwidth connectivity for local area networks and data center environments. This optical assembly utilizes OM2 50/125µm multimode fiber to support Gigabit Ethernet applications over shorter distances compared to single-mode alternatives. It features SC-UPC connectors on both termination points, ensuring a secure push-pull latching mechanism that minimizes the risk of accidental disconnection in high-density rack environments. The duplex configuration enables simultaneous bidirectional data transmission between network switches, transceivers, and patch panels.
Key Features
-
High-Precision Ceramic Ferrules
The SC connectors utilize zirconia ceramic ferrules to maintain precise alignment of the fiber cores during mating. -
OM2 Multimode Performance
This fiber grade supports 1Gbps throughput up to 550 meters at 850nm and 10Gbps up to 82 meters. -
LSZH Safety Compliance
- Low Smoke Zero Halogen jacket material reduces toxic gas emission during combustion.
- Complies with fire safety regulations for poorly ventilated indoor installations.
- Resistant to environmental stress cracking for long-term cable integrity.
Specifications
| Feature | Specification |
|---|---|
| Connector Type | SC to SC |
| Fiber Mode | Multimode OM2 50/125µm |
| Polish Type | UPC (Ultra Physical Contact) |
| Cable Length | 3 Meters |
| Strand Count | Duplex (2 Strands) |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 35 dB |
| Operating Temp | -20°C to +70°C |
What’s in the Box
-
1 x Lightwave 3M SC-SC Duplex OM2 Multimode Fiber Patch Cord
-
Protective Dust Caps for SC Connectors
Why Choose Lightwave Fiber
-
The optical assembly undergoes rigorous factory testing for insertion and return loss to ensure signal integrity.
-
Standardized SC connectors offer a robust mechanical interface compatible with a wide range of legacy and modern hardware.
-
The 3-meter length provides sufficient slack for intra-rack patching without creating excessive cable management overhead.
-
LSZH construction ensures the patch cord meets stringent building codes for commercial and industrial infrastructure.
-
Orange jacket color follows TIA-598 standards for easy identification of OM2 multimode fiber within complex cable bundles.
