Hikvision DS-3E0326P-E/M(B) 24Port Unmanaged PoE Switch
Original price was: KSh 36,000.00.KSh 28,000.00Current price is: KSh 28,000.00.
Hikvision DS-3E0326P-E/M(B) 24Port 100 Mbps Unmanaged PoE Switch
| Ports | 24 × 100 Mbps PoE, 1 × 1G RJ45, 1 × 1G SFP |
| PoE Standard | 802.3af/at (230 W Budget) |
| Max Port Power | 30 W |
| Transmission Distance | Up to 300 m (Extend Mode) |
| Switching Capacity | 8.8 Gbps |
| Temperature Range | -10°C to 55°C |
| Enclosure | Metal |
| Power Input | 100–240 VAC |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
Hikvision DS-3E0326P-E/M(B) 24Port 100 Mbps Unmanaged PoE Switch
The Hikvision DS-3E0326P-E/M(B) 24Port 100 Mbps Unmanaged PoE Switch is a rugged 24-port 100 Mbps Long-Range Unmanaged PoE Switch designed for surveillance, SMB networks, and long-distance PoE transmission deployments. Equipped with 24 × 100 Mbps PoE ports, 1 × 1 Gbps RJ45 uplink, and 1 × 1 Gbps SFP fiber uplink, the switch supports up to 300 m PoE transmission distance, making it ideal for wide-area CCTV installations and distributed LAN setups.
Key Features
24 × 100 Mbps PoE Ports + 1G Uplink
Supports 24 PoE-powered devices with additional Gigabit RJ45 and SFP uplink options.300 m Long-Range PoE Transmission
Extend mode supports up to 300 meters, ideal for remote IP cameras.Intelligent PoE Management
Automatically allocates power and protects ports when power budget exceeds limits.8-Core Adaptive Power Supply
Provides reduced voltage drop and improved power efficiency across long cable runs.6 kV Surge Protection
Built-in lightning protection ensures long-term reliability in harsh environments.VIP Priority Ports (1–8)
Guarantees critical video streams during network congestion.Plug-and-Play Operation
Unmanaged design with simple deployment and zero configuration required.Rugged Metal Housing
Heat-efficient and durable metal enclosure ensures stable 24/7 operation.
Specifications
Network Parameters
| Feature | Specification |
|---|---|
| Port Count | 24 × 100 Mbps PoE, 1 × 1 Gbps RJ45, 1 × 1 Gbps SFP |
| Port Type | RJ45, Full Duplex, MDI/MDI-X Adaptive |
| Supported Standards | IEEE 802.3, 802.3u, 802.3x |
| Forwarding Mode | Store-and-forward |
| Operating Modes | Standard (default), Extend mode |
| High Priority Ports | Ports 1–8 |
| Long-Range Ports | Ports 17–24 |
| MAC Address Table | 4K |
| Switching Capacity | 8.8 Gbps |
| Forwarding Rate | 6.547 Mpps |
| Internal Buffer | 2.75 Mbit |
PoE Power Supply
| Feature | Specification |
|---|---|
| PoE Standards | IEEE 802.3af / IEEE 802.3at |
| PoE Ports | Ports 1–24 |
| PoE Power Pins | 8-core power delivering on pins 1/2/3/6 & 4/5/7/8 |
| Max Power per Port | 30 W |
| Total PoE Budget | 230 W |
| Max Power Consumption | 250 W |
| Idle Power Consumption | 20 W |
General Specifications
| Feature | Specification |
|---|---|
| Enclosure | Metal |
| Net Weight | 2.55 kg |
| Gross Weight | 3.33 kg |
| Dimensions | 335 × 44.5 × 226 mm |
| Operating Temperature | -10°C to 55°C |
| Storage Temperature | -40°C to 85°C |
| Operating Humidity | 5%–95% (non-condensing) |
| Storage Humidity | 5%–95% (non-condensing) |
| Power Supply | 100–240 VAC, 50/60 Hz, Max 4 A |
Certifications
| Category | Standards |
|---|---|
| EMC | FCC Part 15B, CE-EMC, EN 55032, EN 61000-3-2/3-3, RCM, ICES-003 |
| Safety | UL 60950-1, CB, CE-LVD |
| Chemistry | RoHS, WEEE, REACH |
Optional SFP Modules
| Model | Fiber Type | Connector | Data Rate | Wavelength | Distance |
|---|---|---|---|---|---|
| HK-SFP-1.25G-20-1310 | Single-fiber SM | LC | 1.25 Gbps | Tx1310 / Rx1550 nm | 0–20 km |
| HK-SFP-1.25G-20-1550 | Single-fiber SM | LC | 1.25 Gbps | Tx1550 / Rx1310 nm | 0–20 km |
| HK-SFP-1.25G-1310-DF-MM | Duplex MM | LC | 1.25 Gbps | 1310 nm | 0–1 km |
| HK-SFP-1.25G-20-1310-DF | Duplex SM | LC | 1.25 Gbps | 1310 nm | 0–20 km |
What’s in the Box
1 × DS-3E0326P-E/M(B) PoE Switch
Power Cable
Mounting Accessories
Quick Installation Guide
Why Choose the DS-3E0326P-E/M(B)
Long-range PoE up to 300 meters
Ideal for CCTV and long-distance industrial deployments
High 230 W PoE power budget for multi-camera sites
VIP ports ensure uninterrupted surveillance footage
Rugged metal body with surge protection for reliability
Simple plug-and-play unmanaged operation
