D-Link NCB-FM51O-AUHD-12 12-Core OM3 10G Armoured Outdoor Fiber Cable

D-Link 12-Core Armoured Fiber

The D-Link 12-Core OM3 Cable facilitates high-density data transmission across campus backbones and external network infrastructures. This optical medium utilizes 50/125 micrometer laser-optimized multimode fiber to support 10 Gigabit Ethernet applications. It maintains signal integrity over distances up to 300 meters at 850nm. The unitube architecture houses twelve individual color-coded fibers within a central gel-filled buffer tube. This design prevents moisture ingress while allowing for a compact cable diameter. Consequently, the cable remains manageable during complex pulls through outdoor conduits.

Key Features

• Corrugated Steel Tape Armouring
  The integrated CST layer provides superior mechanical protection against rodent damage and high-pressure crushing forces.

• High-Density Polyethylene Sheath

  • Resists ultraviolet radiation for long-term outdoor exposure
  • Provides a robust moisture barrier against groundwater

• OM3 Performance Standards
  This fiber grade supports an effective modal bandwidth of 2000 MHz.km at the 850nm wavelength.

• Unitube Construction
  The central loose tube design protects the internal fibers from thermal expansion and contraction cycles.

Specifications

What’s in the Box

• D-Link NCB-FM51O-AUHD-12 Fiber Cable (Length as ordered)

• Technical Testing Documentation

Why Choose This Fiber Solution

• The armoured jacket ensures network uptime in environments prone to mechanical stress or pests.

• Full compliance with TIA/EIA-568-C.3 standards guarantees interoperability with standard SFP+ transceivers.

• HDPE material offers a lower coefficient of friction during installation compared to PVC alternatives.

• Gel-filled tubes provide reliable protection against hydrogen-induced attenuation in damp environments.
