D-Link NCB-FM51O-AUHD-06 6-Core Multimode OM3 Fiber Optic Cable
Original price was: KSh 250.00.KSh 200.00Current price is: KSh 200.00.
D-Link NCB-FM51O-AUHD-06 6-Core Multimode OM3 Fiber Optic Cable
| Feature | Detail |
|---|---|
| Fiber Grade | OM3 Multimode |
| Core Count | 6 Cores |
| Core/Cladding | 50/125Îĵm |
| Jacket | LSZH (Low Smoke Zero Halogen) |
| Max Speed | 10Gbps up to 300m |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
D-Link 6-Core OM3 Multimode Cable
The D-Link OM3 Fiber Cable (NCB-FM51O-AUHD-06) serves as a high-performance transmission medium for enterprise-grade network backbones and data center interconnects. This 6-core multimode fiber solution utilizes a 50/125 micrometer laser-optimized core to facilitate 10 Gigabit Ethernet speeds over significant distances. Consequently, it remains a standard choice for vertical cabling and high-speed local area networks. The architecture supports 10GBASE-SR and 10GBASE-SW protocols, ensuring compatibility with modern SFP+ transceivers. Additionally, the cable construction prioritizes signal integrity by minimizing modal dispersion during high-frequency data transfers.
Key Features
10Gbps Transmission Support
This media supports 10 Gigabit Ethernet data rates up to 300 meters using 850nm VCSEL sources.6-Core Fiber Configuration
The multi-core design allows for three full-duplex links or multiple redundant paths within a single jacket.LSZH Outer Jacket
The Low Smoke Zero Halogen sheath reduces the emission of toxic gases during thermal decomposition events.Laser-Optimized Performance
- Effective Modal Bandwidth of 2000 MHz·km at 850nm
- Optimized for Vertical-Cavity Surface-Emitting Laser (VCSEL) light sources
Specifications
| Feature | Specification |
|---|---|
| Fiber Type | Multimode OM3 (50/125Îĵm) |
| Core Count | 6 Cores |
| Max Attenuation (850nm) | ⤠3.0 dB/km |
| Max Attenuation (1300nm) | ⤠1.0 dB/km |
| Jacket Material | LSZH |
| Tensile Strength | 600N (Short Term) |
| Bending Radius | 20x Diameter (Dynamic) |
What’s in the Box
D-Link 6-Core OM3 Multimode Fiber Cable (Length as ordered)
Technical Compliance Documentation
Why Choose This Multimode Fiber
High-density core count facilitates efficient cable management in congested server rack environments.
The OM3 standard provides a cost-effective migration path from 1Gbps to 10Gbps networking.
Enhanced safety compliance through the use of flame-retardant, low-smoke materials for indoor installations.
Superior protection against electromagnetic interference ensures clean signal delivery in industrial settings.
Robust physical construction withstands the mechanical stresses associated with vertical shaft deployments.
