Ubiquiti UniFi AC In Wall UAP AC IW Access Point
Upgrade your home or office network with this high-performance WiFi 5 in-wall access point. Designed for seamless connectivity, it delivers fast, reliable wireless coverage while blending perfectly into your wall.
Key Features
-
WiFi 5 Performance
Dual-band 2×2 MU-MIMO provides speeds up to 867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz. -
Compact & Convenient
Sleek wall-mounted design (139.7 x 86.7 x 25.8 mm) with included mount for easy installation. -
Extensive Coverage
Ideal for spaces up to 25 m² (300 ft²), supporting 250+ clients simultaneously. -
Advanced Networking
Features PoE/PoE+ support, guest network isolation, band steering, fast roaming (802.11r), and advanced radio management. -
Secure & Customizable
Supports PPSK, voucher authentication, captive portal with custom branding, and RADIUS over TLS (RadSec).
Specifications
| Feature | Specification |
|---|---|
| WiFi Standard | 802.11ac (WiFi 5) |
| Spatial Streams | 2×2 (both 2.4 GHz & 5 GHz) |
| Max Data Rate | 5 GHz: 867 Mbps (BW80), 2.4 GHz: 300 Mbps (BW40) |
| Coverage Area | 25 m² (300 ft²) |
| Max Client Count | 250+ |
| Antenna Gain | 5 GHz: 2 dBi, 2.4 GHz: 1 dBi |
| Max TX Power | 20 dBm (both bands) |
| Mounting | Wall (Mount Included) |
| Power Method | PoE / PoE+ |
| Networking Interface | 3 x GbE RJ45 |
| Weight | 200 g (6.4 oz) |
| Enclosure Material | Polycarbonate |
| Channel Bandwidth | HT 20/40, VHT 20/40/80 (MHz) |
| Certifications | CE, FCC, IC, Anatel |
| Operating Frequency | 2.4 GHz: 2400–2483.5 MHz, 5 GHz: 5150–5850 MHz |
| Ambient Temp/Humidity | -10 to 50°C, 5–95% noncondensing |
| Application Requirements | UniFi Network Version 6.0.45+ |
| NDAA Compliant | ✓ |
Why Choose Ubiquiti UniFi AC In-Wall UAP-AC-IW
-
Seamless WiFi 5 dual-band performance with MU-MIMO
-
Compact wall-mounted design for minimal footprint
-
Supports up to 250 clients, perfect for homes and small offices
-
Advanced networking and security features including PPSK, captive portal, and RADIUS over TLS
-
NDAA-compliant with CE, FCC, IC certifications
