Secureye S-16GE-M-2UG-LD-AI-VLAN 16Port Manage PoE Switch
Original price was: KSh 55,000.00.KSh 48,000.00Current price is: KSh 48,000.00.
Secureye S-16GE-M-2UG-LD-AI-VLAN 16Port Manage PoE Switch
| Ports | 24 × 10/100/1000 Mbps PoE + 2 SFP |
| PoE Standard | IEEE 802.3af / 802.3at |
| PoE Output per Port | 15.4 W / 30 W |
| Total PoE Budget | < 400 W |
| Switching Capacity | 8.8 Gbps |
| Forwarding Rate | Up to 1.488M pps |
| MAC Table | 16K |
| Transmission Distance | 100–150 m |
| Power Input | AC100–240V, 50/60 Hz |
| Operating Temp | -10°C to 55°C |
| Chassis | Metal, desktop/rack-mountable |
| Weight | 3.9 kg |
| Dimensions | 440 × 285 × 44 mm |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
Secureye S-16GE-M-2UG-LD-AI-VLAN 16Port Layer 2 Managed PoE Switch
The Secureye S-16GE-M-2UG-LD-AI-VLAN 16Port Layer 2 Managed PoE Switch is a 16-port Gigabit Layer 2 Managed PoE Switch designed for high-performance enterprise, IP surveillance, and industrial network deployments. Featuring 16 RJ45 Gigabit ports with PoE+ support and 2 SFP uplink slots, this switch delivers reliable data and power over a single Ethernet cable, providing flexibility for IP cameras, VoIP phones, and other networked devices.
Key Features
16× Gigabit RJ45 PoE+ Ports + 2 SFP Uplinks
Provides full Gigabit connectivity with PoE+ support for IP devices (max 150W, single port up to 46W).High Switching Performance
36 Gbps switching bandwidth, 23.8 Mpps forwarding rate, 8K MAC address table.Advanced PoE Management
AI-based PoE allocation, per-port power limit, priority setting, and scheduling.AI-Enhanced Network Shortcuts
One-key AI VLAN, AI Extend (250 m PoE extension on ports 1–8), AI PoE, and AI QoS for video prioritization.Layer 2–4 Access Control & Security
Supports ACL filtering, port mirroring, IP-MAC-PORT binding, DoS protection, DHCP attack prevention, 802.1X authentication, HTTPS/SSH/SSL secure management.VLAN & Link Aggregation
Supports 4K VLANs, 802.1Q VLAN, MAC/IP/Voice VLANs, and up to 32 aggregation groups with static, dynamic, and hybrid load balancing.Spanning Tree & Loop Protection
Supports STP/RSTP/MSTP with loop protection, root bridge protection, BPDU protection, and TC protection.Multicast & Storm Control
IGMP v1/v2 Snooping, fast leave mechanism, multicast VLAN, multicast filtering, and broadcast/unknown unicast suppression.Comprehensive Management
Web interface, CLI (Telnet/SSH), SNMP v1/v2/v3, LLDP, RMON, ARP protection, IP source guard, CPU/memory monitoring, system log, grading warnings, Ping/Tracert, and cable diagnostics.
Specifications
General
| Feature | Specification |
|---|---|
| Model | S-16GE-M-2UG-LD-AI-VLAN |
| Ports | 16 × 10/100/1000 Mbps RJ45 PoE+, 2 × Gigabit SFP, 1 × Console |
| PoE Power | Max 150W total, Max 46W per port |
| LEDs | 18 Link/Act LEDs, 16 PoE LEDs, 1 SYS LED, 1 Power LED |
| Switching Mode | Store and Forward |
| Bandwidth | 36 Gbps |
| Forwarding Rate | 23.8 Mpps |
| MAC Address Table | 8K |
| Lightning Protection | 6 kV |
| Input Voltage | 100–240V AC, 50/60 Hz |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to 85°C |
| Operating Humidity | 5%–95% (non-condensing) |
Standards & Protocols
| Feature | Specification |
|---|---|
| IEEE Standards | 802.3i, 802.3u, 802.3x, 802.3ab, 802.3af, 802.3at, 802.3z, 802.3ad, 802.1p, 802.1q, 802.1d, 802.1s, 802.1w |
| VLAN Support | 4K VLANs, 802.1Q VLAN, MAC VLAN, IP VLAN, Voice VLAN |
| Spanning Tree | STP, RSTP, MSTP |
| Link Aggregation | Static, Dynamic, Hybrid; up to 32 aggregation groups |
| QoS | 8 queues, 802.1p/DSCP priority, SP/RR/WFQ scheduling |
| Multicast | IGMP v1/v2 Snooping, fast leave, multicast VLAN/filtering |
| Security | ACL L2–L4, port isolation, IP-MAC-PORT binding, 802.1X, DHCP snooping, DoS attack protection |
| Management | Web GUI (HTTP/HTTPS/SSL), CLI (Telnet/SSH), SNMP v1/v2/v3, LLDP, RMON, system log, grading warning |
What’s in the Box
1 × Secureye S-16GE-M-2UG-LD-AI-VLAN Managed PoE Switch
Rack-mounting kit (ears and screws)
Quick Installation Guide
Power Cable
Why Choose S-16GE-M-2UG-LD-AI-VLAN
High-performance 16-port Gigabit PoE+ connectivity for IP cameras, phones, and IoT devices
Advanced AI-enabled PoE, VLAN, and QoS for optimized surveillance and enterprise networks
Full Layer 2–4 security and network control
Supports extensive link aggregation, spanning tree, and multicast management
Web, CLI, SNMP, and remote management capabilities
