Secureye S-16GE-2UG-1UF-300W-NB 16+2+1 Gigabit PoE Switch
Original price was: KSh 30,000.00.KSh 23,000.00Current price is: KSh 23,000.00.
Secureye S-16GE-2UG-1UF-300W-NB 16+2+1 Gigabit PoE Switch
| Ports | 16 × PoE + 2 × Uplink + 1 × SFP |
| PoE Standard | IEEE 802.3af/at |
| PoE Power | 30 W per port, 300 W total |
| Switching Capacity | 38 Gbps |
| Throughput | 28.272 Mpps |
| Transmission Distance | Up to 100 m over copper; SFP dependent |
| Power Supply | Built-in 300 W |
| Operating Temp | 0°C to 55°C |
| Storage Temp | -20°C to 70°C |
| Humidity | 20–95% |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
Secureye S-16GE-2UG-1UF-300W-NB 16+2+1 Gigabit PoE Switch
The Secureye S-16GE-2UG-1UF-300W-NB is a high-performance 16+2+1 port Gigabit PoE switch designed for enterprise, surveillance, and SMB networks that require robust power-over-Ethernet capabilities. Supporting IEEE 802.3af/at standards, the switch delivers up to 30 W per PoE port and a total PoE budget of 300 W, making it ideal for IP cameras, wireless access points, and VoIP phones.
Key Features
16× Gigabit PoE Ports + 2 Uplink + 1 SFP Port
Provides versatile network expansion with PoE support for IP devices.IEEE 802.3af/at Compliance
Supports PoE end-span powering, delivering 15.4 W (af) or 30 W (at) per port.High Power Capacity
Built-in 300 W power supply with per-port priority ensures uninterrupted device operation.Advanced Network Protection
VLAN segmentation, network storm restraint, and lightning protection (4 kV) safeguard network integrity.Flexible Transmission
Supports up to 100 m over standard Cat5/5e/6 cables; SFP distance depends on module type (20–100 km).Intelligent Switching Architecture
Store-and-forward design, full-duplex IEEE 802.3X flow control, MAC learning and aging for efficient packet forwarding.LED Indicators for Easy Monitoring
Displays link/activity, 100 Mbps status, PoE status, and power presence.
Specifications
Power
| Feature | Specification |
|---|---|
| Power Adapter Voltage | AC 110–240 V |
| Maximum Power Consumption | 300 W |
| PoE Maximum per Port | 30 W |
| Idle Power Consumption | N/A |
| PoE Priority | Yes |
| Lightning Protection | 4 kV |
Network Connector & Transmission
| Feature | Specification |
|---|---|
| PoE Ethernet Ports | 16 × 10/100/1000 Mbps |
| Uplink Ports | 2 × 10/100/1000 Mbps |
| SFP Port | 1 × 1000 Mbps |
| Transmission Distance | 1–16 Ports: 0–100 m; Uplink: 0–100 m; SFP: depends on module |
| Transmission Medium | Cat5/5e/6 |
Network Switch Parameters
| Feature | Specification |
|---|---|
| Network Standards | IEEE 802.3/802.3u/802.3x/802.3ab |
| Switching Capacity | 38 Gbps |
| Packet Buffer Memory | 1 Mbit |
| Throughput | 28.272 Mpps |
| MAC Address Table | 2K |
| Packet Forwarding Rate | 10 Mbps: 14,880 pps/port, 100 Mbps: 148,800 pps/port, 1000 Mbps: 1,488,000 pps/port |
PoE Features
| Feature | Specification |
|---|---|
| PoE Standard | IEEE 802.3af/at |
| PoE Power Supply | End-Span (1/2+; 3/6-) |
| PoE Power | af=15.4 W, at=30 W |
Port & Function
| Feature | Specification |
|---|---|
| RJ45 Port Function | MAC auto-learning & aging, Full/Half duplex support |
| Switching Mode | Fast-forward store-and-forward |
| Link Aggregation | N/A |
| LED Indicators | LINK/ACT, 100 Mbps, PoE Status, Power |
Environmental
| Feature | Specification |
|---|---|
| Operating Temperature | 0°C to 55°C |
| Relative Humidity | 20–95% |
| Storage Temperature | -20°C to 70°C |
What’s in the Box
1 × Secureye S-16GE-2UG-1UF-300W-NB Gigabit PoE Switch
Quick Installation Guide
Power Cable
Why Choose Secureye S-16GE-2UG-1UF-300W-NB
Enterprise-grade 16+2+1 port PoE switch with high power capacity.
Supports IEEE 802.3af/at PoE for IP cameras, access points, and VoIP devices.
VLAN, network storm protection, and lightning safeguards for reliable operation.
Flexible fiber or copper uplink via SFP or Gigabit ports.
Store-and-forward architecture with MAC learning and aging for efficient switching.
LED indicators for real-time port and PoE status monitoring.
