Rawlplug Rawlbolt Anchor M6 Loose Bolt Zinc Plated

Rawlbolt M6 Anchor

The Rawlplug Rawlbolt Anchor M6 serves as a high-performance mechanical expansion shield designed for heavy-duty applications in solid masonry and non-cracked concrete. This specific loose bolt variant provides versatility for installers who require the ability to remove or replace the bolt while keeping the expansion shield seated within the substrate. Consequently, it remains a primary choice for securing structural steelwork, heavy machinery, and infrastructure components. The engineering behind this fastener ensures reliable performance under significant tensile and shear loads. Therefore, it is frequently specified for critical installations where mechanical grip is paramount.

Key Features

• Three-Segment Expansion Shield
  The internal mechanism utilizes a three-piece shield that expands uniformly against the wall of the drill hole to maximize surface contact.
• Substrate Compatibility
  • Non-cracked concrete (C20/25 to C50/60)
  • Solid clay brick units
  • Reinforced concrete structures
  • Natural stone with high density
• Zinc Plated Finish
  A protective zinc coating provides essential resistance against oxidation and environmental degradation during indoor service life.
• Collapsible Ferrule Design
  The integrated ferrule ensures that the fixture is pulled tightly against the substrate during the final torque application.

Specifications

What’s in the Box

• Rawlplug M6 Expansion Shield
• M6 Hex Head Loose Bolt
• Standard Flat Washer

Why Choose This Anchor

• The torque-controlled expansion mechanism provides high load-bearing capacity even in older masonry substrates.
• This fastener allows for the removal of the bolt without disturbing the embedded shield, facilitating equipment maintenance.
• Moreover, the specialized ferrule prevents the anchor from spinning in the hole during the initial tightening phase.
• Additionally, the all-steel construction ensures fire resistance and structural integrity under thermal stress.
• The precision-engineered taper nut ensures the shield opens fully and consistently across all three segments.
