OfficePoint FG-1 Automatic Voltage Fridge Guard, 5 Amps, 230V

OfficePoint FG-1 Voltage Guard

The OfficePoint Fridge Guard provides essential protection against power fluctuations that damage refrigeration compressors and sensitive electronics. This automatic voltage switcher monitors the incoming utility power and disconnects the load when voltage levels deviate from safe operating parameters. Consequently, it prevents the overheating of motor windings and potential insulation failure caused by under-voltage or over-voltage conditions. The internal microprocessor logic ensures precision monitoring, while the integrated delay timer protects the compressor against back-pressure during rapid power cycling.

Key Features

• Automatic Voltage Monitoring
  The unit continuously tracks the AC input and disconnects the output if the voltage drops below 185V or exceeds 260V.

• Integrated Startup Delay

  • Provides a 180-second wait time before reconnecting power
  • Ensures refrigerant pressures equalize before the compressor restarts
  • Reduces inrush current stress on the electrical circuit

• Spike and Surge Suppression
  Internal metal oxide varistors (MOVs) clamp high-voltage transients caused by lightning or grid switching to safe levels.

• LED Status Indicators

  • Red LED indicates high or low voltage disconnection
  • Yellow LED signals the active wait period for pressure equalization
  • Green LED confirms the output is active and within safe limits

Specifications

What’s in the Box

• OfficePoint FG-1 Automatic Voltage Guard

• User Instruction Manual

Why Choose this Voltage Protector

• This protection device eliminates the risk of motor burnout during frequent brownouts common in industrial and residential grids.

• The FG-1 architecture utilizes flame-retardant plastic housing to enhance fire safety in 24/7 operating environments.

• The 5-amp capacity supports a wide range of appliances including domestic refrigerators, freezers, and water dispensers.

• Users benefit from a maintenance-free operation as the system resets automatically once the utility power stabilizes within the 185V to 260V window.
