OfficePoint 9U 600x600mm Wall Mount Cabinet with 6-Way PDU and Fan Group

9U Wall Mount Data Rack

The OfficePoint 9U Cabinet serves as a high-density enclosure for networking switches, patch panels, and small-scale server equipment. This 600x600mm unit provides sufficient depth for most modern rack-mountable hardware while maintaining a compact footprint for wall installations. The enclosure utilizes a heavy-duty cold-rolled steel frame to ensure structural integrity under maximum load. Consequently, network engineers can deploy this solution in telecommunications closets or office environments where floor space remains limited. The integrated 19-inch mounting rails allow for precise hardware alignment and secure fastening.

Key Features

• Thermal Management System
  The unit includes a pre-installed NC-WM66-2WF fan group to facilitate active heat dissipation from sensitive electronic components.

• Power Distribution Unit
  A 6-way PDU comes integrated into the chassis to provide centralized power management for all mounted devices.

• Equipment Support

  • Includes one NC-WM66-SH fixed tray measuring 496x430mm
  • Supports non-rackmountable hardware such as routers or small UPS units
  • Adjustable mounting profiles for depth flexibility

• Security and Access
  The front door features toughened glass for visual monitoring and a key lock mechanism to prevent unauthorized hardware tampering.

Specifications

What’s in the Box

• 9U 600x600mm Wall Mount Enclosure

• 1x NC-WM66-SH Fixed Tray

• 1x NC-WM66-2WF Fan Group

• 1x 6-Way Power Distribution Unit

• Key Set for Front Door

• Assembly Hardware and Cage Nuts

Why Choose this Data Enclosure

• The 600mm depth accommodates deeper network switches and mid-sized UPS systems compared to standard shallow cabinets.

• Integrated cooling components reduce the risk of hardware failure caused by thermal throttling in enclosed spaces.

• Removable side panels simplify maintenance tasks and initial cabling procedures during network deployment.

• Electrostatic powder coating provides resistance against corrosion and environmental wear in industrial settings.

• Compliance with international 19-inch rack standards ensures compatibility with hardware from all major B2B technology manufacturers.
