Netgear GS305PP 5xGE Unmanaged 4xPoE+ 83W Plus Switch
The Netgear GS305PP is a compact, unmanaged Gigabit Ethernet switch designed to deliver reliable, high-speed connectivity for small to medium-sized business networks. Featuring 5 Gigabit Ethernet ports, including 4 PoE+ ports with a total 83W power budget, it allows seamless deployment of powered devices such as IP cameras, access points, and VoIP phones without the need for additional power adapters.
Key Features
-
5 Gigabit RJ-45 Ports
Provides high-speed connectivity with 4 PoE+ ports for powering devices directly over Ethernet. -
Power over Ethernet (PoE+)
Supports up to 30W per port with a total budget of 83W, ideal for IP devices without external power sources. -
Unmanaged Plug-and-Play
Simplifies installation and operation with auto-sensing and auto MDI/MDI-X capabilities. -
Robust Networking Standards
Compliant with IEEE 802.3, 802.3ab, 802.3u, 802.3x, and 802.1p for reliable Ethernet performance. -
Metal Housing & Wall Mountable
Durable construction ensures stable operation, suitable for wall or desktop deployment. -
Energy Efficient & Low Latency
Forwarding rate of 1.448 Mpps, 10 Gbit/s switching capacity, and 2.4 µs latency at 1 Gbps. -
Jumbo Frame Support
Handles frames up to 9216 bytes for improved network efficiency with large data transfers.
Specifications
| Feature | Specification |
|---|---|
| Model | Netgear GS305PP |
| Switch Type | Unmanaged |
| Switch Layer | L2 |
| Ports | 5 × Gigabit RJ-45 (4 PoE+) |
| PoE+ Ports Power | 30 W per port |
| Total PoE Budget | 83 W |
| Forwarding Rate | 1.448 Mpps |
| Switching Capacity | 10 Gbit/s |
| MAC Address Table | 2000 entries |
| Latency (1 Gbps) | 2.4 µs |
| Jumbo Frames | 9216 bytes |
| Packet Buffer Memory | 128 MB |
| Networking Standards | IEEE 802.1p, 802.3, 802.3ab, 802.3az, 802.3i, 802.3u, 802.3x |
| Power Source | DC 54 V |
| Power Consumption (Max/Typical) | 88.89 W / 2.89 W |
| Housing Material | Metal |
| Dimensions (W × D × H) | 158 × 101 × 29 mm |
| Weight | 410 g |
| Operating Temperature | 0–40 °C |
| Storage Temperature | -20–70 °C |
| Operating Humidity | 10–90% |
| Storage Humidity | 5–95% |
| Mounting | Wall mountable |
| LED Indicators | Activity, Link, PoE, Power |
| Certifications | CE, FCC, IC, RCM, CCC, VCCI, CB |
What’s in the Box
-
1 × Netgear GS305PP 5xGE Unmanaged Plus Switch
-
User Manual / Quick Start Guide
Why Choose Netgear GS305PP
-
Compact, plug-and-play solution for small to medium business networks.
-
Provides reliable PoE+ connectivity for IP cameras, access points, and VoIP devices.
-
High switching capacity with low latency ensures seamless network performance.
-
Durable metal housing for long-term operation and wall mounting flexibility.
-
Supports jumbo frames and QoS for improved traffic management.
