NEC IP7WW-308U 3 Analog Trunks 8 Hybrid Extensions Card

NEC IP7WW-308U Interface Board

The NEC IP7WW-308U Expansion Card provides a high-density interface solution for the NEC SL2100 communication system. This hardware module integrates three analog Central Office (CO) trunks and eight hybrid extension ports into a single slot-in unit. Consequently, IT administrators can scale system capacity without occupying multiple chassis slots. The architecture supports both legacy PSTN connectivity and internal station distribution. Furthermore, the hybrid design allows for flexible deployment of diverse terminal types across the network infrastructure.

Key Features

• Integrated Trunk Interface
  Three analog circuit ports facilitate direct connection to traditional public switched telephone network (PSTN) lines.

• Hybrid Extension Versatility

  • Supports NEC digital multiline terminals for advanced feature access.
  • Provides connectivity for standard single-line analog (SLT) devices.
  • Automatically detects terminal type upon connection to the RJ61 interface.

• Modular Daughterboard Support
  This interface includes a dedicated mounting position for one IP7WW-008U-C1 or IP7WW-000U-C1 daughterboard.

• Power Failure Transfer
  One built-in PFT circuit ensures emergency communication remains active during total power loss.

Specifications

What’s in the Box

• NEC IP7WW-308U-A1 Expansion Card
• Mounting Hardware and Screws
• Installation Quick Guide

Why Choose this Interface

• The unit optimizes rack space by combining trunking and station distribution on a single PCB.
• Hybrid technology allows procurement managers to reuse existing analog handsets while migrating to digital multiline terminals.
• The integrated daughterboard slot provides a path for future expansion to 6 trunks or 16 extensions without replacing the base card.
• Standardized RJ61 connectors simplify cabling for network engineers using structured wiring systems.
• Native integration with the SL2100 KSU ensures plug-and-play recognition and simplified programming via PC Pro software.
