Hikvision DS-3E0505P-E 4Port Gigabit Unmanaged PoE Switch
Original price was: KSh 9,500.00.KSh 8,000.00Current price is: KSh 8,000.00.
Hikvision DS-3E0505P-E 4Port Gigabit Unmanaged PoE Switch
| Ports | 4 × Gigabit PoE + 1 × Gigabit Uplink |
| PoE Standard | 802.3af/at |
| Max PoE Per Port | 30 W |
| PoE Budget | 60 W |
| Switching Capacity | 10 Gbps |
| Forwarding Rate | 7.44 Mpps |
| Installation | Desk/Wall |
| Enclosure | Metal, fanless |
| Surge Protection | 6 kV |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
Hikvision DS-3E0505P-E 4Port Gigabit Unmanaged PoE Switch
The Hikvision DS-3E0505P-E 4Port Gigabit Unmanaged PoE Switch is a compact yet powerful 4-port Gigabit Unmanaged PoE Switch engineered specifically for stable, high-quality video data transmission in surveillance and small enterprise networks. Equipped with 4 × Gigabit PoE ports and 1 × Gigabit uplink, the switch supports both IEEE 802.3af and 802.3at power standards, delivering up to 30 W per port and a total 60 W PoE power budget.
Key Features
4 × Gigabit PoE Ports + 1 × Gigabit Uplink
High-speed Ethernet access with dedicated uplink for smooth video transmission.High-Power PoE Output
Supports IEEE 802.3af/at, delivering up to 30 W per port and 60 W total PoE budget.Optimized for Surveillance
Built for stable video streaming with store-and-forward switching.Industrial-Grade Protection
6 kV surge protection ensures stable performance in harsh electrical environments.Fanless Metal Housing
Silent, robust, and thermally efficient.Plug-and-Play
No configuration required — ideal for rapid deployment.Supports IEEE 802.3 Standards
Fully compliant with 802.3/802.3u/802.3x/802.3ab/802.3z.
Specifications
General
| Feature | Specification |
|---|---|
| Shell | Metal, fan-free design |
| Net Weight | 0.26 kg |
| Gross Weight | 0.84 kg |
| Dimensions | 105 × 27.6 × 83.1 mm |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 85°C |
| Operating Humidity | 5%–95% (non-condensing) |
| Power Supply | 48 V DC, 1.35 A |
| Max Power Consumption | 65 W |
| Idle Power Consumption | 5 W |
| Installation Mode | Desk/Wall mounted |
| Surge Protection | 6 kV |
Network Parameters
| Feature | Specification |
|---|---|
| Ports | 4 × Gigabit PoE ports, 1 × Gigabit RJ45 uplink |
| MAC Address Table | 2K |
| Switching Capacity | 10 Gbps |
| Packet Forwarding Rate | 7.44 Mpps |
| Internal Cache | 1 Mbit |
PoE Power Supply
| Feature | Specification |
|---|---|
| PoE Standard | IEEE 802.3af / IEEE 802.3at |
| PoE Pin Assignment | End-span 1/2 (+), 3/6 (–) |
| PoE Ports | Ports 1–4 |
| Max Port Power | 30 W |
| Total PoE Budget | 60 W |
Certifications & Compliance
| Category | Certification |
|---|---|
| EMC | FCC, CE-EMC, ICES-003, RCM |
| Safety | UL 60950-1, CB (IEC 62368-1), CE-LVD |
| Chemistry | RoHS (2011/65/EU) |
What’s in the Box
1 × Hikvision DS-3E0505P-E PoE Switch
Power Adapter (48 V DC)
Quick Installation Guide
Wall-mounting accessories
Why Choose the DS-3E0505P-E
Designed specifically for IP surveillance networks
Delivers stable, high-bandwidth PoE power for cameras
Rugged metal enclosure for long-term durability
Zero-configuration deployment — plug and play
Ideal for homes, offices, shops, and small CCTV projects
Strong surge protection for electrical reliability
