Hikvision DS-3D2208P 8Port PoE + 4 Gigabit Smart Switch

Original price was: KSh 40,000.00.Current price is: KSh 35,800.00.

Hikvision DS-3D2208P 8Port PoE + 4 Gigabit Smart Switch


PoE Ports	8 × 10/100BASE-T
Gigabit Ports	2 × 10/100/1000BASE-T
SFP Ports	2 × 1000M
Console	1 × RJ45, 9600 bps
Power Consumption	Max. 170 W
Dimensions	340 × 200 × 44 mm
Operating Temp	0°C – 60°C
Humidity	10% – 85%
Protocol Support	VLAN, STP, RSTP, LAG, QoS, PoE

Add to compare

Add to wishlist

Shipping & Delivery

Fast delivery

Your order will be deliver to the specified address

15 - 45 minutes

From KES 300

Warranty 1 year

More details

Free 30-Day returns

More details

Unbeatable offers

Black Friday Blowout!

Description

Hikvision DS-3D2208P 8Port PoE + 4 Gigabit Smart Switch

The Hikvision DS-3D2208P is an 8-Port 10/100Base-T PoE + 2 Gigabit Ethernet + 2 Gigabit SFP Smart Switch designed for small to medium-sized networks, surveillance systems, and enterprise deployments. It delivers intelligent Layer 2 management, high PoE power output, and flexible installation options for desks or cabinets.

Key Features

8× 10/100BASE-T PoE Ports
Supports IEEE 802.3af/at, delivering power over Ethernet to connected devices such as IP cameras and access points.
2× 10/100/1000BASE-T Ports & 2× 1000M SFP Ports
High-speed uplinks for backbone connections and fiber integration.
Console Port for Local Management
RJ45 console interface for setup and monitoring via terminal software.
Robust Hardware Design
Durable metal chassis with desk or cabinet mounting options.
Flexible Installation
Can be installed on desks, open racks, or enclosed cabinets with appropriate ventilation.
Advanced Layer 2 Features
Supports IEEE 802.1d Spanning Tree Protocol (STP), IEEE 802.1s Multiple STP, VLAN (802.1Q), Link Aggregation (802.3ad), and Flow Control (802.3x).
RoHS Compliant
Environmentally friendly design following international standards.

Specifications

Ports & Hardware

Feature	Specification
PoE Ports	8 × 10/100BASE-T, RJ45, PoE LED indicator
Gigabit Ports	2 × 10/100/1000BASE-T, RJ45
SFP Ports	2 × 1000M SFP optical
Console Port	1 × RJ45, 9600 bps for local management
LEDs	Power (PWR), System (SYS), Link/ACT, PoE status
Memory	EPROM: 512 KB; Flash: 8 MB; SDRAM: 64 MB
Dimensions	340 × 200 × 44 mm
Power Consumption	Max. 170 W
Input Voltage	AC 100–240 V, 47–63 Hz

Environmental Conditions

Parameter	Range
Operating Temperature	0°C – 60°C
Operating Humidity	10% – 85% (non-condensing)
Storage Temperature	-40°C – 80°C
Storage Humidity	5% – 95% (non-condensing)

Protocol & Standards

Category	Standards Supported
Spanning Tree	IEEE 802.1d, 802.1s
VLAN	IEEE 802.1q tagged VLAN
QoS	IEEE 802.1p Class of Service
Flow Control	IEEE 802.3x, IEEE 802.3z asymmetric
Link Aggregation	IEEE 802.3ad
PoE	IEEE 802.3af/at
Routing Protocols	RIP, RIP v2 (RFC 1058, RFC 1723), OSPF v2 (RFC 1583)
Network Management	SNMP v1/v2 (RFC 1157), MIB II (RFC 1213), RMON 1,2,3,9 (RFC 1757)

Installation Overview

Desk Mounting: Direct placement on stable, flat surfaces. Do not place objects over 4.5 kg on the chassis.
Cabinet Installation: Fixed with brackets; ensure proper airflow to avoid overheating.
Power Requirements: AC 100–240V, properly grounded. Use fuses or breakers for safety.
Installation Tools: Screwdriver, static armguard, bolts, Ethernet cables, and terminal devices.

Port Connections

Port Type	Connection Method
Console	RJ45 to DB9, 9600 bps, 8 data bits, 1 stop bit, no parity, no flow control
10/100M PoE	UTP cable, supports MDI/MDIX auto-identification
1000M Ethernet	Standard RJ45 direct-through or cross cable, LED link/ACT indicator
1000M SFP	Insert SFP module, connect fiber optic cable to terminal device
