Grandstream GWN7813P 24Port Layer 3 Managed PoE Switch
Original price was: KSh 48,000.00.KSh 47,000.00Current price is: KSh 47,000.00.
Grandstream GWN7813P 24Port Layer 3 Managed PoE Switch
| Gigabit Ethernet Ports | 24 (PoE/PoE+, PoE++ Ports 1–8) |
| 10G SFP+ Ports | 4 |
| Maximum PoE Output per Port | 60 W (Ports 1–8), 30 W (Ports 9–24) |
| Total PoE Output | 370 W |
| Switching Capability | 128 Gbps |
| Forwarding Rate | 95.232 Mpps |
| VLAN | 4K VLANs, QinQ, Voice VLAN |
| Stacking | Up to 4 devices |
| Routing | IPv4/IPv6, RIP, OSPF, BGP |
| Security | ARP Inspection, IP Source Guard, DoS, Port Security |
| Management | Web GUI, CLI, SNMP, GDMS, GWN Manager |
| Dimensions | 440 × 300 × 44 mm |
| Weight | 4.69 kg |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
Grandstream GWN7813P 24Port Layer 3 Managed PoE Switch
The Grandstream GWN7813P is a Layer 3 managed PoE network switch designed for medium-to-large enterprise networks requiring high-performance, scalable, and secure connectivity with advanced Power over Ethernet (PoE/PoE+) capabilities. Featuring 24 Gigabit Ethernet ports with PoE support and 4 × 10G SFP+ uplinks, this switch can power devices such as IP cameras, IP phones, Wi-Fi access points, and other PoE endpoints directly through the network cable.
Key Features
24 Gigabit Ethernet Ports + 4 × 10G SFP+ Uplinks
High-speed connectivity with PoE/PoE+ and PoE++ support on select ports.Dynamic PoE Power Allocation
Smart power distribution per port, up to 60W per port (PoE++), with priority-based allocation.Advanced Layer 2 & 3 Networking
VLANs, QinQ, Voice VLAN, IPv4/IPv6 dual-stack, static and dynamic routing.Enterprise-Grade Security
Port security, ARP inspection, IP/MAC binding, DoS attack prevention, DHCP snooping.Stacking Support
Stack up to 4 switches for centralized management and redundancy.Energy-Efficient Operation
EEE (Energy Efficient Ethernet) and intelligent fan control reduce energy consumption.
Specifications
| Feature | Specification |
|---|---|
| Model | GWN7813P |
| Ports | 24 × Gigabit Ethernet (PoE/PoE+, PoE++ on Ports 1–8), 4 × 10G SFP+ |
| PoE Standards | IEEE 802.3af/at/bt |
| Max PoE Output per Port | 60W (Ports 1–8, PoE++), 30W (Ports 9–24) |
| Max Total PoE Output | 370 W |
| Switching Capability | 128 Gbps |
| Forwarding Rate | 95.232 Mpps |
| Packet Buffer | 12 MB |
| Memory | 256 MB RAM, 128 MB NAND Flash, 8 MB NOR Flash |
| Jumbo Frame | 12288 bytes |
| Stacking | Up to 4 devices |
| Routing | IPv4/IPv6 static & dynamic routing, RIP, OSPF, BGP |
| Multicast | IGMPv2/v3, MLDv1/v2, 256 groups |
| VLAN Support | 4K VLANs, 16 VLAN virtual interfaces, QinQ, Voice VLAN |
| Security | 802.1X, MAC, RADIUS, AAA, TACACS+, storm control, port isolation, DoS protection |
| Management | Web GUI, CLI, SNMP v1/v2c/v3, GWN Manager, GDMS Networking |
| Operating Temp | 0°C – 45°C |
| Storage Temp | -10°C – 60°C |
| Dimensions | 440 × 300 × 44 mm |
| Weight | 4.69 kg |
| Certifications | FCC, CE, RCM, IC, UKCA |
What’s in the Box
1 × GWN7813P Switch
1 × 1.2 m AC Power Cable
1 × 25 cm Ground Cable
4 × Rubber Footpads
1 × Power Cord Anti-Trip
8 × Screws (KM 3*6)
1 × Quick Installation Guide
1 × Console Cable (Optional)
2 × Rack-Mounting Kits
1 × Optional RPS (External Redundant Power Supply)
Why Choose GWN7813P
Enterprise-grade L3 switch with 24 Gigabit ports and PoE/PoE++ support
High-speed backbone with 4 × 10G SFP+ uplinks
Intelligent PoE management with dynamic allocation and priority settings
Stackable for simplified management of multiple switches
IPv4/IPv6 dual-stack and advanced routing for enterprise networks
Robust enterprise security and traffic management capabilities
Energy-efficient with intelligent fan control and EEE support
