Grandstream GWN7700P 5Port Gigabit Unmanaged PoE+ Switch
The Grandstream GWN7700P is a 5-port unmanaged Gigabit switch with 4 PoE+ ports, ideal for powering devices such as IP phones, cameras, and Wi-Fi access points while delivering high-speed connectivity. It features plug-and-play installation, auto-negotiation, and auto MDI/MDIX capabilities, eliminating the need for complex setup or crossover cables.
Key Features
-
5× Gigabit RJ45 Ports with 4 PoE+ Outputs
Delivers power and data over a single cable to PoE-enabled devices. -
Plug-and-Play Design
No configuration needed; perfect for SMBs and home offices. -
Auto-Negotiation & MDI/MDIX
Automatic adjustment to network device speeds and cable types. -
Smart PoE Management
Dynamic allocation with 30 W per port; overload protection prioritizes higher-priority ports. -
Advanced Traffic Control
Supports QoS, storm control, and long-distance connections. -
Durable Metal Enclosure
Ensures robust operation in professional network environments.
Specifications
| Feature | Specification |
|---|---|
| Ports | 5 × 10/100/1000 Mbps RJ45 |
| PoE Ports | 4 (IEEE 802.3af/at, up to 30 W per port, 60 W total) |
| Enclosure | Metal |
| Mounting | Desktop / Wall-Mount |
| Network Protocols | IEEE 802.3i, 802.3u, 802.3ab, 802.3x, 802.1p |
| Switching Capacity | 10 Gbps |
| Forwarding Rate | 7.44 Mpps |
| Jumbo Frame | 9 KB |
| MAC Address Table | 2K |
| LEDs | Per port: Link/Activity Green; PoE Output Yellow; Device: Power Green |
| Power Adapter | External 48–53.5VDC / 1.22A |
| Max Power Consumption | 2 W (excluding PoE) |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Operating Humidity | 10% to 90% Non-condensing |
| Storage Humidity | 10% to 90% Non-condensing |
| Dimensions (L×W×H) | 145 × 80 × 27 mm |
| Weight (Unit) | 0.26 kg |
| Compliance | FCC, CE, RCM, IC, UKCA |
What’s in the Box
-
1 × GWN7700P Switch
-
1 × Power Adapter
-
1 × Quick Installation Guide (QIG)
Why Choose GWN7700P
-
Combines Gigabit switching with PoE+ power for IP devices
-
Plug-and-play, no configuration needed
-
Dynamic PoE management with priority control
-
Compact metal design suitable for SMB deployments
-
Energy-efficient operation with advanced traffic management
