Generic HDMI Extender 120m Over IP TCP/IP Cat5e/Cat6 1080p

HDMI Extender 120m

The Generic HDMI Extender 120m provides a robust solution for long-distance audio and video transmission over standard networking infrastructure. This hardware set utilizes the TCP/IP protocol to convert HDMI signals into data packets. Consequently, users can extend high-definition signals up to 120 meters using a single Cat5e or Cat6 Ethernet cable. The architecture supports point-to-point configurations and point-to-multipoint distribution through managed network switches. This versatility allows IT professionals to integrate AV signals into existing local area networks without dedicated proprietary cabling. The system ensures signal integrity through digital packetization, maintaining a stable 1080p output at the receiver end.

Key Features

• Extended Transmission Range
  The transmitter and receiver pair facilitates signal delivery up to 120 meters over high-quality Cat6 copper cabling.
• TCP/IP Protocol Integration
  • Enables signal routing through standard Ethernet switches.
  • Supports one-to-many distribution via IGMP-capable network hardware.
  • Simplifies installation by using standard RJ45 termination standards.
• High-Definition Resolution Support
  This hardware maintains native 1080p resolution at 60Hz while ensuring HDCP 1.4 compliance for protected content playback.
• Advanced Signal Processing
  • Uses H.264 compression to manage bandwidth consumption effectively.
  • Features automatic EDID synchronization for seamless display detection.
  • Provides IR pass-through for remote control of source devices from the display end.

Specifications

What’s in the Box

• HDMI Extender Transmitter (TX) Unit
• HDMI Extender Receiver (RX) Unit
• Two (2) 5V DC Power Adapters
• IR TX and IR RX Cables
• User Installation Manual

Why Choose this Extender

• The device leverages standard networking hardware, reducing the need for expensive specialized AV cabling installations.
• Integrated H.264 encoding ensures that the video stream remains stable even in environments with moderate network traffic.
• Support for point-to-multipoint allows engineers to broadcast a single HDMI source to multiple screens using a network switch.
• The metal housing provides efficient heat dissipation and EMI shielding for industrial or commercial environments.
