Fanvil CS20 Audio Peripheral
The Fanvil CS20 Portable Speakerphone provides a high-performance audio solution for professional huddle rooms and mobile workstations. This device integrates advanced digital signal processing (DSP) to ensure clear communication during high-density voice conferences. It features a compact, disc-shaped chassis designed for portability and desktop stability. The internal hardware supports both wired and wireless connectivity, allowing users to switch between laptop and mobile device inputs seamlessly. This unit utilizes a high-sensitivity microphone array to capture audio from all directions, ensuring that every participant in a small meeting room remains audible to remote parties. Additionally, the integrated speaker provides wide-band audio output for natural-sounding voice reproduction.
Key Features
- Omnidirectional Voice Pickup
The integrated microphone array captures sound in a 360-degree radius with an effective range of up to 3 meters. - Advanced Signal Processing
- Acoustic Echo Cancellation (AEC) removes feedback loops during full-duplex communication.
- Environmental Noise Cancellation (ENC) filters out background hums from HVAC systems and hardware.
- Automatic Gain Control (AGC) balances voice levels regardless of the speaker’s distance from the unit.
- Dual Connectivity Modes
Users can connect via USB-C for driverless plug-and-play operation or utilize Bluetooth 5.0 for wireless pairing with smartphones.
Specifications
| Feature | Specification |
|---|---|
| Connectivity | Bluetooth 5.0 / USB 2.0 Type-C |
| Pickup Range | 360-degree, 3-meter radius |
| Battery Capacity | 2000mAh Lithium-ion |
| Battery Life | Up to 8 hours talk time |
| Speaker Output | 5W High-fidelity speaker |
| Control Interface | Capacitive touch buttons (Mute, Volume, Call) |
What’s in the Box
- Fanvil CS20 Speakerphone Unit
- USB Type-C to Type-A Cable
- Portable Carrying Case
- Quick Installation Guide
Why Choose This Speakerphone
- The device ensures full-duplex communication, allowing simultaneous two-way conversation without audio clipping or latency.
- Internal hardware DSP reduces processor load on the host computer by handling audio encoding and noise filtering locally.
- The 2000mAh battery supports extended operation for long-duration meetings without requiring an external power source.
- Cross-platform compatibility ensures the hardware works with major Unified Communications (UC) applications including Zoom, Teams, and Skype.
