EVI 1000VA/900W Rack Mount Online UPS – EP-UPS1000UC13OR

EVI 1000VA/900W UPS

The EVI 1000VA/900W Rack Mount Online UPS is a single-phase UPS designed for rack mounting. It features online double conversion technology, ensuring a stable power supply. This UPS supports a wide input voltage range from 110 to 300 Vac and has an input power factor of 0.99 with PFC. The output power factor is 1.0. It offers selectable output voltages of 200, 208, 220, 230, and 240 Vac.

Key Features

• Online Double Conversion
  This topology provides the highest level of power protection by isolating the output from input disturbances.

• Wide Input Voltage Range
  The UPS functions within a broad input voltage spectrum (110-300 Vac), minimizing battery usage during voltage fluctuations.

• Selectable Output Voltage
  Users can select from multiple output voltages (200, 208, 220, 230, 240 Vac) to suit specific equipment requirements.

• Smart Battery Charging

  • Optimizes battery performance and extends battery life.
  • Supports lithium batteries and Battery Management Systems (BMS).
  • Offers selectable charging current of either 1A or 2A, with 2A charging current for two groups of installed batteries.

Specifications for EVI 1000VA/900W Rack Mount Online UPS

What’s in the Box

• EVI 1000VA/900W UPS
• USB Cable
• RS232 Cable
• Power Cord
• User Manual

Why Choose EVI 1000VA/900W UPS

• Provides continuous, high-quality power, safeguarding critical equipment from power disturbances.
• Its rack-mount design saves space in server rooms and data centers.
• It is generator compatible, ensuring extended runtime during prolonged power outages.
• The unit features communication ports (USB, RS232) and optional SNMP card for remote monitoring and control.
