D-Link NCB-6AUGRYR-305 Cat6a UTP 305M Grey Cable

D-Link Cat6a UTP 305M

The D-Link Cat6a UTP Cable provides high-performance infrastructure for 10GBASE-T Ethernet applications across enterprise environments. This NCB-6AUGRYR-305 model utilizes 23 AWG solid bare copper conductors to ensure optimal electrical conductivity and signal integrity. It supports 10 Gigabit Ethernet over distances up to 100 meters. Consequently, it meets the rigorous demands of modern data centers and server rooms.

Key Features

• High Bandwidth Capacity
  This transmission medium operates at frequencies up to 500 MHz to double the throughput of standard Category 6 cabling.

• Internal Crosstalk Mitigation
  A central cross-filler or spline separates the four twisted pairs to maintain structural symmetry and reduce internal interference.

• Professional Grade Construction

  • 23 AWG solid bare copper prevents signal degradation compared to CCA alternatives.
  • The flame-retardant PVC jacket provides durability during installation through conduits.

Specifications

Network engineers can deploy this solution in environments requiring Power over Ethernet (PoE). It remains compatible with IEEE 802.3af, 802.3at (PoE+), and 802.3bt (Type 3 & 4) standards. Therefore, it successfully powers high-wattage devices like PTZ cameras and Wi-Fi 6 access points. The sequential meter marking on the jacket allows installers to track remaining length accurately during large-scale deployments.

What’s in the Box

• 1 x 305M Roll D-Link NCB-6AUGRYR-305 Cat6a UTP Cable

Why Choose This Cabling

• The unshielded configuration simplifies termination processes and reduces the need for specialized grounding hardware.

• Full compliance with ANSI/TIA-568.2-D and ISO/IEC 11801 standards ensures interoperability with standard RJ45 connectors.

• Solid copper cores offer superior mechanical strength and lower DC resistance compared to copper-clad aluminum.
