D-Link DMC-810SSC Gigabit Media Converter 1000Base-T to 1000Base-LX Single-mode SC
Original price was: KSh 7,000.00.KSh 6,800.00Current price is: KSh 6,800.00.
D-Link DMC-810SSC Gigabit Media Converter 1000Base-T to 1000Base-LX Single-mode SC
| Feature | Details |
|---|---|
| Conversion | 1000Base-T to 1000Base-LX |
| Fiber Type | Single-mode (9/125 µm) |
| Connector | SC Type |
| Max Range | 15 km |
| Wavelength | 1310 nm |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
D-Link DMC-810SSC Converter
The D-Link DMC-810SSC Media Converter functions as a high-performance bridge between 1000Base-T copper RJ-45 interfaces and 1000Base-LX single-mode fiber SC interfaces. This hardware solution enables network engineers to extend Gigabit Ethernet segments beyond the 100-meter limitation of standard copper cabling. Additionally, the device supports a maximum fiber cable distance of up to 15 kilometers. Consequently, it is a critical component for campus-wide networking or connecting remote office buildings. The architecture utilizes a 1310nm wavelength for signal transmission over 9/125 µm single-mode fiber optic lines.
Key Features of D-Link DMC-810SSC Media Converter
Auto MDI/MDIX Support
The copper port automatically detects and configures the correct connection type for straight-through or crossover cables.Link Pass Through Functionality
- Minimizes troubleshooting time by propagating link failures across segments.
- Ensures the connected switch can detect a broken fiber link immediately.
Duplex Mode Flexibility
This unit supports both full-duplex and half-duplex operations to maintain compatibility with diverse networking hardware.Chassis Compatibility
- Operates as a standalone unit with the included power adapter.
- Integrates into the DMC-1000 19-inch chassis for high-density rack deployments.
Specifications
| Feature | Specification |
|---|---|
| Standards | IEEE 802.3ab, IEEE 802.3z |
| Fiber Connector | Single-mode SC Connector |
| Copper Connector | RJ-45 (1000Base-T) |
| Max Distance | 15 Kilometers |
| Wavelength | 1310 nm |
| Fiber Cable Type | 9/125 µm Single-mode Fiber |
| Power Input | 5V / 1A External Power Adapter |
| LED Indicators | Power, Link/Act |
What’s in the Box
- DMC-810SSC Media Converter Unit
- External Power Adapter
- User Documentation and Installation Guide
Why Choose This Converter
- The device provides seamless integration between legacy copper infrastructure and modern long-range fiber backbones.
- Engineers benefit from the hot-swappable design when used within a centralized management chassis.
- It maintains signal integrity over long distances without the electromagnetic interference common in copper wiring.
- The solid metal housing provides efficient heat dissipation for 24/7 mission-critical network operations.
