D-Link DEM-QX10Q-LR4 40GBASE-LR4 QSFP+Transceiver 10 km

Original price was: KSh 80,000.00.Current price is: KSh 75,000.00.


Data Rate	40 Gbps
Wavelengths	1271, 1291, 1311, 1331 nm
Distance	10 km
Fiber Type	Single-Mode (9/125 μm)
Connector	Duplex LC
DDM Support	Yes
Voltage	3.3 V
Hot-Swappable	Yes
Form Factor	QSFP+
Compliance	IEEE 802.3ba, MSA, RoHS

Shipping & Delivery

Fast delivery

Your order will be deliver to the specified address

15 - 45 minutes

From KES 300

Warranty 1 year

More details

Free 30-Day returns

More details

Unbeatable offers

Black Friday Blowout!

Description

D-Link DEM-QX01Q-SR4 40GBASE-SR4 QSFP Multi Transceiver

The D-Link DEM-QX01Q-SR4 is a high-performance 40GBASE-SR4 QSFP+ optical transceiver designed for ultra-fast data center, enterprise, and carrier-grade network applications. Utilizing Quad Small Form-factor Pluggable Plus (QSFP+) technology, this transceiver supports four transmit and four receive channels, each operating at up to 10.5 Gb/s, enabling a total aggregated bandwidth of 40 Gbps over multi-mode fiber (MMF).

Engineered for high-density switching environments, the DEM-QX01Q-SR4 provides exceptional reliability and scalability for short-range interconnects between switches, routers, and servers. It operates on an 850 nm wavelength and supports transmission distances up to 100 meters on OM3 and 150 meters on OM4 multimode fiber, making it ideal for top-of-rack (ToR), middle-of-row (MoR), and spine-leaf data center architectures.

Key Features

40G Ethernet Connectivity
Delivers blazing 40 Gbps throughput, ensuring superior bandwidth for data-intensive enterprise and cloud applications.
Quad Channel QSFP+ Interface
Integrates four transmit and four receive channels, each supporting up to 10.5 Gb/s for seamless data aggregation.
Digital Diagnostics Monitoring (DDM)
Real-time monitoring of temperature, transmit/receive optical power, and supply voltage for proactive maintenance.
Hot-Swappable Design
Allows module insertion or replacement without powering down the switch, reducing downtime and simplifying upgrades.
MSA & IEEE Compliant
Fully conforms to IEEE 802.3ba 40GBASE-SR4 and Multiple Source Agreement (MSA) standards, ensuring multi-vendor compatibility.
Environmentally Friendly
Fully RoHS compliant, reducing hazardous substances in accordance with international safety and environmental directives.

Specifications

Feature	Specification
Model	D-Link DEM-QX01Q-SR4
Type	40GBASE-SR4 QSFP+ Transceiver
Form Factor	QSFP+
Wavelength	850 nm
Fiber Type	Multi-Mode (OM3 / OM4)
Connector Type	MPO (1×12 Female)
Distance (OM3)	100 m
Distance (OM4)	150 m
Channels	4 Transmit / 4 Receive
Data Rate (Per Channel)	10.5 Gb/s
Aggregate Data Rate	40 Gb/s
Power Supply Voltage	3.3 V
Hot-Pluggable	Yes
DDM Support	Yes
Standards Compliance	IEEE 802.3ba, MSA
RoHS Compliant	Yes
Operating Temperature	0 °C to 70 °C
Storage Temperature	-40 °C to 85 °C
Typical Applications	Data Centers, Enterprise Core Networks, Service Provider Transport

What’s in the Box

1 × D-Link DEM-QX01Q-SR4 40GBASE-SR4 QSFP+ Multi-Mode Transceiver
Quick Installation / Datasheet Document

Why Choose D-Link DEM-QX01Q-SR4

Ideal for high-speed data center interconnects and short-reach aggregation links.
Supports 40G Ethernet for scalable, future-ready infrastructure.
Simplifies maintenance with hot-swap functionality.
Built for interoperability across multi-vendor networks.
Integrated DDM enhances reliability through real-time optical link monitoring.
Energy-efficient, RoHS-compliant design ensures sustainable operation.
