D-Link DAP-1360 Wireless N300 Access Point 7 Operating Modes

D-Link DAP-1360 N300

The D-Link DAP-1360 Access Point serves as a versatile networking solution designed to extend the reach of existing wireless infrastructures or create new local area networks. This hardware complies with the IEEE 802.11n standard, delivering data throughput speeds of up to 300 Mbps. It utilizes a 2.4 GHz frequency band to ensure broad compatibility with legacy 802.11b/g devices while providing the enhanced bandwidth required for modern business applications. The system architecture supports seven distinct operating modes, allowing network administrators to tailor the device to specific environmental requirements. Consequently, this unit functions efficiently as a bridge, a repeater, or a client depending on the software configuration selected during deployment.

Key Features

• Seven Configurable Operating Modes
  This hardware supports Access Point, Wireless Client, Bridge, Bridge with AP, Repeater, WISP Client Router, and WISP Repeater modes.

• Advanced Wireless Security Protocols

  • WPA and WPA2 encryption standards protect data transmission from unauthorized access.
  • Built-in MAC address filtering provides granular control over which hardware can associate with the network.
  • Wi-Fi Protected Setup (WPS) button facilitates rapid, secure device integration.

• Enhanced Signal Coverage
  The integration of two 5dBi external antennas improves signal stability and reduces dead zones in complex indoor environments.

Technical Specification Analysis

This networking component features a single 10/100 Mbps Fast Ethernet port for wired backhaul or local device connectivity. The firmware includes a user-friendly web-based management interface, enabling rapid configuration of SSID, channel selection, and security parameters. Furthermore, the WISP (Wireless Internet Service Provider) modes allow the device to share a single wireless Internet connection with multiple wired or wireless clients without requiring an additional dedicated router. This functionality is particularly useful for small office environments or remote branch locations where infrastructure may be limited. The inclusion of an EU plug and a compact form factor ensures easy installation in standard rack shelves or wall-mounted configurations.

Specifications

What’s in the Box

• D-Link DAP-1360 Wireless N300 Unit

• Power Adapter (EU Plug)

• Two Detachable Antennas

• Ethernet Cable

• Quick Install Guide

Why Choose This Networking Solution

• The multi-mode capability eliminates the need for purchasing separate hardware for bridging or repeating functions.

• High-gain 5dBi antennas provide superior penetration through physical obstacles compared to standard internal antennas.

• WISP client functionality enables flexible internet distribution in areas without traditional wired infrastructure.

• Backward compatibility ensures that existing 802.11b/g assets remain functional within the upgraded network topology.
